4 Hearth & Home Technologies • GFK-210-C Blower System Instructions 2201-938 Rev. E • 9/12
NOTE: IF ANY OF THE ORIGINAL
WIRE AS SUPPLIED WITH THE
APPLIANCE MUST BE REPLACED,
IT MUST BE REPLACED WITH
TYPE 105
0
C RATED WIRE.
BLOWERS
BLOWER
RECEPTACLE
BLK
GRN
BLK
BLK
GRN
BLK
WHT
GRN
BLK
BLK
GRN
WHT
BLK
BLK
BLK
BLK
PLUG INTO 120V
EXISTING OUTLET
TEMPERATURE
SENSOR SWITCH
VARIABLE SPEED
CONTROL
DC REGULATOR
RECEPTACLE
BLOWER
CORD
POWER
CORD
PLUG
120V EXISTING
OUTLET
BRN
RED
BLACK
TO VALVE
TO VALVE BRACKET
(GROUND)
ORG
GRN
BLOWER
VARIABLE
SPEED
CONTROL
(RHEOSTAT)
TEMPERATURE
SENSOR
SWITCH
CONTROL
PANEL
POWER CORD
BLOWER
CORD
DETAIL A
Figure 7. Fan Wiring Diagram - Metal Insert Without RC200/RC300
ZIP TIES
DETAIL A
