Page 6SKU 99835 For technical questions, please call 1-800-444-3353.
Rotate the Thrust Handle (13) clock-4.
wise until the chain rivet is held
against the Spinner Die (11).
Check again to be sure the rivet is 5.
lined up with the Dies and the open-
ings in the chain links.
Apply a small amount of oil to the 6.
faces of the Dies (11 and 12).
Turn the Spinner Handle (7) clock-7.
wise to begin forming the rivet head.
At the same time, slowly turn the
Thrust Handle (13) to keep the rivet
centered and provide resistance to
the pressure applied by the Spinner
Die.
Once the rivet head is formed, turn 8.
both the Spinner Handle (7) and
Thrust Handle (13) counterclockwise
to release the chain.
Check the rivet to be sure is is prop-9.
erly formed. Check the chain to be
sure it is not damaged and moves
freely.
MAINTENANCE AND
SERVICING
Procedures not
specically explained in this
manual must be performed only
by a qualied technician.
TO PREVENT
SERIOUS INJURY FROM
TOOL FAILURE:
Do not use damaged
equipment. If abnormal noise
or binding occurs, have the
problem corrected before
further use.
Cleaning, Maintenance, and
Lubrication
BEFORE EACH USE,1. inspect the
general condition of the Tool. Check
for loose screws, misalignment or
binding of moving parts, cracked or
broken parts and any other condition
that may affect its safe operation.
AFTER USE,2. clean external surfaces
of the Tool with clean, moist cloth.
Occasionally coat bare metal com-3.
ponents with a light coating of oil to
prevent corrosion.
Store this tool in a dry location away 4.
from moisture or corrosive materials.
PLEASE READ THE FOLLOW-
ING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS
PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN
THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER
THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO
THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE
ANY REPAIRS TO THE PRODUCT, OR THAT HE OR
SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE
PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS
AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN
BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT
BY THE BUYER. THE BUYER ASSUMES ALL RISK AND
LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
