Page 11SKU 95781
For technical questions, please call 1-800-444-3353.
SPRAY NOZZLE (14)
FOUNTAIN NOZZLE (15)
FIGURE J
IMPORTANT: Dogs and larger pets will probably prefer that you remove the
Mushroom Head (2) and Mushroom Stand (17) and replace them with the includ-
ed Spray Nozzle (14) or Fountain Nozzle (14-1). (See Figures H and J.)
6.
To install the Spray Nozzle (14) or Fountain Nozzle (14-1):
a. Remove the Mushroom Head (2) and Mushroom Stand (17).Remove the Mushroom Head (2) and Mushroom Stand (17).
(See Figure H.)
into the bottom of the Mushroom Stand (17). (See Figures A, B, and H.)
c. Separate the two Clear Tubes (12) at the black union. Then remove the blackSeparate the two Clear Tubes (12) at the black union. Then remove the black
union and the short length of the Clear Tube (12) (See Figures A and B.)
d. To use the Spray Nozzle (14), slip the male end of it (14) into the longestTo use the Spray Nozzle (14), slip the male end of it (14) into the longest
length of Clear Tube (12) that connects to the Water Pump (11).
To use it with the Fountain function (14-1), remove the spray cover (14-2).
(See Figures A, B and J.)
the Black Lever (13), which the Clear Tube passes through. (See Assembly
diagram.)
INSPECTION, MAINTENANCE, AND CLEANING
WARNING! Make sure the Power Switch of the AC/DC Adapter (9) is in its
“OFF” position and that the Pet Water Fountain is unplugged from its electrical outlet
before performing any inspection, maintenance, or cleaning procedures.
BEFORE EACH USE, inspect the general condition of the Pet Water Fountain.
Check for misalignment or binding of moving parts, cracked or broken parts, dam-
aged electrical wiring, and any other condition that may affect its safe operation. If
abnormal noise or vibration occurs, have the problem corrected before further use.
Do not use damaged equipment.
7.
1.
2.
(14) Spray Nozzle
(14-1) Fountain Nozzle
(14-2) Spray Cover
Figure J
REV 07j
