Page 10SKU 95781
For technical questions, please call 1-800-444-3353.
MUSHROOM HEAD (2)
MUSHROOM STAND (17)
AC/DC ADAPTER (9)
TIMER UNIT (10)
FIGURE H
FIGURE I
Insert the Mushroom Head (2) onto the Mushroom Stand (17).
(See Figure H.)
Connect the AC/DC Adapter (9) to the Timer Unit (10). Then connect the Timer
Unit to the Power Cord of the Water Pump (11). NOTE: Should you not want to
use the Timer Unit, you can remove it and connect the AC/DC Adapter directly to
the Power Cord of the Water Pump. (See Figure I.)
OPERATING INSTRUCTIONS
Plug the AC/DC Adapter (9) into the nearest 120 volt, grounded electrical outlet.
The Water Pump (11) should start and water will come out from the nozzle or
from the Mushroom Head (2). (See Figures H and I.)
Check the position of the Switch on the Timer Unit (10). Slide the Switch to 30
Min. to turn the Water Pump (11) ON for 30 minutes and OFF for 30 minutes
repeatedly. Or slide the Switch to 60 Min. to turn the Water Pump ON for 60 min-
utes and OFF for 60 minutes repeatedly. (See Figure I.)
NOTE: Slide the Switch on the Timer Unit (10) to the OFF position to turn off the
Water Pump (11). It is recommended to unplug the AC/DC Adapter (9) if the Pet
Water Fountain will not be used for long periods of time. (See Figure I.)
Water flow speed can be adjusted by sliding the small window located on the
Water Pump’s (11) side next to where the water flows out.
