Page 5For technical questions, please call 1-800-444-3353.SKU 67378
SPECIFICATIONS
Electrical Input 6 AA Batteries (not included)
Earphone Jack 3.5 mm mini-jack Socket
Functions
Sensitivity Adjuster;
Metal-Type Discriminator;
All-Metal Indicator; Tone
Adjuster; Volume Control;
Target Locator; Low Battery
Indicator; Auto Ground
Balance; Mode Selector
UNPACKING
When unpacking, make sure the item
is intact and undamaged. If any parts
are missing or broken, call Harbor Freight
Tools at 1-800-444-3353.
INSTRUCTIONS FOR
PUTTING INTO USE
Read the ENTIRE IMPORTANT
SAFETY INFORMATION
section at the beginning of this
manual including all text under
subheadings therein before set
up or use of this product.
TO PREVENT
SERIOUS INJURY
FROM ACCIDENTAL
OPERATION:
Turn the Power Switch of the
tool off and remove the
batteries before assembling
or making any adjustments to
the tool.
Note: For additional information regarding
the parts listed in the following pages,
refer to the Assembly Diagram near
the end of this manual.
Components & Controls
Lower Leg (18)
Upper Leg (15)
Control Box
Battery
Cover
(26)
Handle (8/10)
Arm Support (13)
Earphone Jack
Search Coil (23)
Knob Bolt (22)
Cable (25)
Figure 1
Lock Nut (20)
View Meter (36)
Coil Pivot (21)
