4
ITEM
N0. PART N0. DESCRIPTION
1 181618 Bolt, Hex 5/16-24 x 1-3/4
2 13412P1 Nut, Lock Esna 5/8-18 Light Thin
3 12871P1 Spring
4 12867P1 Plate, Dog
5 12870P1 Washer, Friction
6 12869P1 Plate, Drive
7 12868P1 Plate, Back
8 18277P1 Nut, Lock Esna 5/16-24 Light Thin
9 13143P1 Bearing, Race
13144P1 Bearing, Cone
10 13122P1 Seal, Oil
11 12550P1 Retainer, Oil Seal
12 11815P1 Shaft, Housing
13 94110100 Fitting, Lube 1/8
14 435507 Nut, Lock 1/2-13 Washer Insert Hex
15 180193 Bolt, Hex 1/2-13 x 3-3/4
16 180122 Bolt, Hex 3/8-16 x 1
17 138542 Washer, Lock 3/8 Int Tooth
18 12023P1 Casting, Swivel
19 12566P1 Shaft, Drive
20 13145P1 Bearing, Roller Race
13146P1 Bearing, Roller Cone
21 12862P1 Gear, Bevel
22 120502 Key, Woodruff 3/16 x 7/8 Hard
23 13187P1 Ring, Retaining
24 14101P1 Shim, Gear .020
12490P1 Shim, Gear House .005
25 12491P1 Gasket
26 10499P1 Plug, Pipe 2 In. W/Filler Plug
27 9236P1 Housing, 42 In. Mower
28 103877 Plug, Pipe 1/8 In. Sq. Hd.
29 119120 Pin, Cotter 3/32 x 1-1/4
30 125384 Nut, Slotted 5/8-18 Hex Thick
31 12850P1 Gear, Bevel
32 9229P1 Bolt, Hex Special
33 12852P1 Shim, Gear
13646P1 Shim, Gear .010
34 13142P1 Bearing, Roller Cone
35 13139P1 Bearing, Roller Cone
36 13171P1 Seal, Oil (Dual Lip)
37 11363P1 Shaft, Drive Rotor
38 11366A1 Plate, Mounting Weldment
39 120384 Washer, Lock 1/2 Spring
40 120378 Nut, Hex 1/2-13
41 11364P1 Sheave, Drive
42 11365P1 Nut, Special
NS 10102A1 Attachment Clutch Assembly
ILLUSTRATED PARTS LIST (Cont.)
fig 5
