Specications
Specications
Model Numbers
Serial Nos: 790,000 and Higher
PHZ19KA343; PHZ19KA343CA
Systems
Engine
• Engine Specications: See your Engine Owner’s
Manual
• RPM: Full Speed: 3750 ±100 RPM (No Load)
Idle: 1400 RPM
Fuel System
• Capacity: 7.7 gal. (29.1 L)
• Type of Fuel: Regular unleaded gasoline, 87
octane or higher.
• Fuel Filter: In-line Kawasaki P/N 49019–7001
• Fuel Shut-Off Valve: 1/4 turn increments (“ON”,
“OFF”)
Electrical System
• Charging System: Flywheel Alternator
• Charging Capacity: 13 amps
• Battery Type: BCI Group U1
• Battery Voltage: 12 Volt
• Polarity: Negative Ground
• Fuses: Two 20 amp blade type
Safety Interlock System
• PTO must be disengaged, brake engaged, and
motion control levers out (neutral lock) to start
engine. (It is not necessary for the operator to be
in the seat to start the engine.)
• Operator must be in seat when PTO is engaged,
brake is disengaged, or motion control levers are
moved in or engine will stop.
• Engine will stop if either the left, the right, or
both levers are moved from neutral lock position
while brake is engaged.
Operator Controls
• Steering and Motion Control:
Note: Motion control levers are adjustable to
two heights.
– Separate levers, on each side of the console,
control speed and direction of travel of the
respective drive wheels.
– Steering is controlled by varying the position
of the levers relative to each other.
– Moving motion control levers outward (in
slots) locks the drive system in neutral.
• PTO Engagement Switch: Engages electric clutch
(to drive belt) which engages mower blades.
• Parking Brake Lever: Engages parking brake.
• Deck Height Adjustment Lever: Sets cutting
height to desired position.
• Deck Lift Assist Lever: Foot pedal that assists
in raising the deck.
Seat
• Type: Standard seat with high back, foam padded,
(internal suspension) and armrests.
• Mounting: Hinged to tilt up for access to battery
and other components. Held in tilted position
with lanyard. Adjustable fore and aft seat track.
• Armrests: Standard–foam padded ip-up
armrests.
• Seat Safety Switch: Incorporated into the
Safety Interlock System. Time delay seat switch
eliminates rough ground cut-outs.
Hydrostatic Ground Drive System
• Hydrostatic Drive: Two Hydro Gear ZT2800
Integrated drive systems.
• Hydraulic Oil Type: Use Exmark Premium Hydro
Oil.
13
