Maintenance
2. Disconnect the wire from the spark plug (see
Figure 9 and Figure 10).
3. Pull upward on the back of the cover to unsnap
the front and back cover tabs (see
Figure 30).
4. Lift off the cover and brush out all the debris
around the belt area.
5. Install the belt cover by pushing down on the rear
rst and then snapping the front onto the mower
housing.
6. Connect the wire to the spark plug.
Cleaning the Blade
Brake Clutch Shield
(Blade Brake Clutch Units
Only)
Service Interval: Every 50 hours
1. Stop the engine and wait for all moving parts to
stop.
2. Disconnect the wire from the spark plug (see
Figure 9 and Figure 10).
3. Drain the gasoline from the fuel tank. Refer to
Emptying the Fuel Tank and Cleaning the
Fuel Filter section.
4. Tip the lawn mower onto its right side (air lter
up).
5. Remove the blade nuts and the blade (see
Figure 24).
Figure 34
1. Screws 2. BBC Shield
6. Remove the three screws holding the BBC shield
onto the unit (see Figure 34).
7. Remove the BBC shield and brush or blow all
the debris from under the shield and around the
BBC system.
8. Install the BBC shield. Tighten the screws to
secure the BBC shield to the deck.
9. Install the blade and the two blade nuts.
10. Turn the lawn mower upright.
11. Connect the wire to the spark plug.
Cleaning Under the Cover
Plate (Non-Blade Brake
Clutch Units Only)
Service Interval: Every 50 hours
1. Stop the engine and wait for all moving parts to
stop.
2. Disconnect the wire from the spark plug (see
Figure 9 and Figure 10).
3. Drain the gasoline from the fuel tank. Refer to
Emptying the Fuel Tank and Cleaning the
Fuel Filter section.
4. Tip the lawn mower onto its right side (air lter
up).
5. Remove the blade bolt, blade support, and the
blade (see
Figure 24).
Figure 35
1. Blade bolt
4. Cover plate
2. Blade support
5. Screw
3. Blade
6. Remove the three screws holding the cover plate
onto the unit (see Figure 35).
7. Remove the cover plate and brush or blow all the
debris from under the plate.
31
