MOTION CONTROL GROUP
11
Item
Part No.
Description
Qty.
1 1-303105 Yoke, Adjustable....................................2
2 1-323245 Spring, Compression .............................2
3 1-403180 Screw, HH 5/16-18 X 1 1/4 Sp ...............4
4 1-543017 Balljoint..................................................2
5 1-603735 Bushing, Flanged...................................2
6 1-603737 Bolt, Neutral Return ...............................2
7 1-603807 Spring ....................................................2
8 1-633102 Bearing, Flanged....................................4
9 1-633152 Balljoint, (LH) .........................................2
10V 1-803022 Setscrew, 5/16-18 X 5/8.........................2
11 1-804524 Nut, Hex 5/16-24 (LH)............................4
12 1-808280 Pin, Clevis 5/16 X 1................................2
13 98-5975 Washer, Spring Disc 3/8 ........................6
14 103-1361 Spacer ...................................................2
15 103-3457 Asm, Handle W/Grip (LH) ......................1
16 103-3458 Asm, Handle W/Grip (RH)......................1
17 103-3456 Grip, Control Lever.................................2
18 109-3623 Wld, Lever Control (LH) .........................1
19 109-3622 Wld, Lever Control (RH).........................1
20 103-8262 Tab, Motion Cntrl ...................................2
21 109-3618 Wld, Control Shaft..................................2
22 3290-357 Nut, Whizlock 3/8-16..............................8
Item
Part No.
Description
Qty.
23 3296-29 Nut, Nyloc 5/16-18.................................4
24 32128-20 Nut, Whizlock 5/16-18 ........................... 8
25 106-5335 Washer, Wave....................................... 6
26 109-0558-03 Wld, Pump Ctrl (RH) (23HP)..................1
103-8286-03 Wld, Pump Ctrl (RH) (27HP) ................. 1
27 109-0559-03 Wld, Pump Ctrl (LH) (23HP) .................. 1
103-8285-03 Wld, Pump Ctrl (LH) (27HP) ..................1
28 109-1198 Link, Tracking Rod (23HP)..................... 2
103-8300 Link, Tracking Rod (27HP)..................... 2
29 109-2339 Damper, Motion Control......................... 2
30 322-12 Screw, HH 5/16-18 X 2 1/2 .................... 2
31 322-6 Screw, HH 5/16-18 X 1 1/4 .................... 2
32 323-4 Screw, HH 3/8-16 X 3/4 .........................10
33 323-6 Screw, HH 3/8-16 X 1 ............................4
34 3217-6 Nut, Hex 5/16-18....................................4
35 3219-2 Nut, Hex 5/16-24....................................6
36 3220-2 Nut, Jam 5/16-24...................................6
37 3256-2 Washer, 1/4 Std..................................... 2
38 3272-5 Pin, Cotter 3/32 X 1/2 ............................ 2
39 109-2583 Asm, Tracking Rod (23HP).................... 2
109-2582 Asm, Tracking Rod (27HP).................... 2
Exmark black touch up spray paint – Gloss black.
V Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on screw, item #10 & screw, item #32 going into control shaft
weldment item #21.
