Operation
Figure 11
1. Roll bar upper hoop
2. Knob in “latched” position
3. Pull knob to unlatch
4. Rotate 90° to hold unlatched
5. Knob in “unlatched” position
5. Make sure the knobs are fully engaged with the
roll bar in the raised position. The upper hoop of
the roll bar may need to be pushed forward or
pulled rearward to get both knobs fully engaged
(see Figure 12).
Figure 12
1. Engaged 2. Partially engaged — Do
Not operate with ROPS
in this condition.
Important: Always use the seat belt with the
roll bar in the operate (raised) position. Ensure
that the rear part of the seat is secured with the
seat latch.
Open the Fuel Shut-Off Valve
Rotate the valve and align with the fuel line to open.
Starting the Engine
1. Move the motion control levers out to the neutral
lock position.
2. Pull up and back on the parking brake lever to
engage the parking brake.
3. Push down on the PTO switch to the “disengage”
position.
Note: It is not necessary for the operator to be
in the seat to start the engine.
4. Place the throttle midway between the “SLOW”
and “FAST” positions.
5. On a cold engine, push the choke lever forward
into the “ON” position.
On a warm engine, leave the choke in the “OFF”
position.
6. Turn ignition switch to the “START” position.
Release the switch as soon as the engine starts.
Important: Do Not crank the engine
continuously for more than ten seconds at a
time. If the engine does not start, allow a 60
second cool-down period between starting
attempts. Failure to follow these guidelines
can burn out the starter motor.
7. If the choke is in the “ON” position, gradually
return choke to the “OFF” position as the engine
warms up.
Engaging the PTO
DANGER
The rotating blades under the mower deck are
dangerous. Blade contact can cause serious
injury or kill you.
Do Not put hands or feet under the mower or
mower deck when the blades are engaged.
DANGER
An uncovered discharge opening will allow
objects to be thrown in an operator’s or
bystander’s direction. Also, contact with the
blade could occur. Thrown objects or blade
contact can cause serious injury or death.
Never operate the mower with the discharge
deector raised, removed, or altered unless there
is a grass collection system or mulch kit in place
and working properly.
22
