Specications
– Moving motion control levers outward (in
slots) locks the drive system in neutral.
• PTO Engagement Switch: Engages electric clutch
(to drive belt) which engages mower blades.
• Parking Brake Lever: Engages parking brake.
• Deck Height Adjustment Lever: Sets cutting
height to desired position.
• Deck Lift Pedal: Foot pedal that lifts deck.
• Transport Lock: Latching position: Automatically
latches at the transport position.
Seat
• Type: Standard seat with foam padded seat
cushion with armrests and integral safety switch.
Optional seat: Seat with high back, extra
wide foam padded seat cushion with internal
suspension, thick bolstering, two-tone cover,
armrests, integral safety switch, and seat vibration
isolation system.
Optional seat accessories for units with standard
seats:
– Custom ride suspension system to enhance
Standard Seat. Adds approximately 3 inches
(7.6 cm) to seat height.
– Deluxe suspension seat with high back,
(dampened, adjustable spring suspension),
armrests, and integral safety switch. Adds
approximately 1/2 inch (1.3 cm) to seat height.
• Mounting: Adjustable fore and aft on seat tracks.
• Armrests: Molded ip-up armrests.
• Seat Safety Switch:
Integrated seat switch. Time delay seat switch
eliminates rough ground cut-outs.
Hydrostatic Ground Drive System
• Two unitized hydrostatic transmissions:
Hydro Gear ZT2800
• Hydraulic Oil Type: Exmark Premium Hydro Oil.
• Hydraulic Oil Capacity: 77 oz (2.3 L) per side
• Hydraulic Filter: P/N 109-3321
• Speeds:
– 0-7 mph (11.3 km/hr) forward.
– 0-4 mph (6.4 km/hr) reverse.
• Drive wheel release valves allow machine to be
moved when engine is not running.
Tires & Wheels
Drive Front Caster
Pneumatic (Air
lled)
Pneumatic (Air
lled)
Quantity
2 2
Tread
Turf Master Smooth
Size 20 x 8.00-10 13 x 5.00-6
Ply Rating
4
2
Pressure
13 psi (90 kPa) 13 psi (90 kPa)
Cutting Deck
• Cutting Width:
– 48 inch Deck: (121.9 cm)
– 52 inch Deck: (132.1 cm)
• Discharge: Side
• Blade Size: (3 ea.)
– 48 inch Deck: 16.25 inches (41.3 cm)
– 52 inch Deck: 18.00 inches (45.7 cm)
• Blade Spindles: Solid steel spindles with .67 inch
(17 mm) I.D. bearings.
• Deck Drive: “B” Section belt with self-tensioning
idler.
• Electric clutch: 125 ft-lb Mag Stop
• Deck: Full oating deck is attached to out-front
support frame. Anti-scalp rollers provide
maximum turf protection. Deck design allows for
bagging, mulching or side discharge.
– 48 inch Deck: 3 anti-scalp rollers
– 52 inch Deck: 3 anti-scalp rollers
• Deck Depth:
– 48 inch Deck: 4.0 inches (10 cm)
– 52 inch Deck: 4.0 inches (10 cm)
• Cutting Height Adjustment:
Foot activated lever is used to adjust the cutting
height from 1 1/2 inch (3.8 cm) to 5 inches (12.7
cm) in 1/4 inch (6.4 mm) increments.
• Mulching Kit: Optional.
16
