ENGINE GROUP – 23HP KAWASAKI
-27-
Item Part No. Description Qty.
2 1-303334 Washer, Spring Disc 5/16......................4
3 109-6919 Washer, Clutch......................................1
4 1-603610 Washer, Spring Disc 7/16......................2
5 1-807259 Key, Machine 1/4 x 1/4 x 1.....................1
6 104-8301 Nut, Nyloc 3/8-16 Flg .............................1
7 109-9280 Muffler, Small Engine.............................1
8 109-9905 Sheave, W/Hub......................................1
9 109-4490 Asm, Hose Oil Drain W/Plug..................1
9:2 109-1012 Plug .......................................................1
10 109-9282 Clutch, CMS-200 W/Spot Brake.............1
11 109-9254 Bracket, Muffler......................................1
12 109-9251 Manifold, Exhaust ..................................1
Item Part No. Description Qty.
13 109-8138-01 Anchor, Clutch....................................... 1
14 322-9 Screw, HH 5/16-18 x 1 3/4..................... 4
16V 109-9761 Screw, HH 7/16-20 x 1 1/2 W/Loctite..... 1
17 3231-22 Bolt, Carriage 3/8-16 x 1........................1
18 3296-29 Nut, Nyloc 5/16-18.................................4
19 94-2413 U-Nut 5/16-18........................................ 2
20 3234-5 Screw, HH FLG 5/16-18 x 3/4................2
21 322-2 Screw, HH 5/16-18 x 5/8........................ 3
23 2412-98 Clamp, Hose.......................................... 2
24 105-1853 Clamp-Hose, Hydro...............................1
25 3253-4 Washer, Lock 5/16 ................................ 3
26 109-0296 Hose, Fuel 15”.......................................1
Exmark red touch up paint (spray paint – P/N 1-850337 - .6 oz liquid bottle – P/N 103-9140)
V Use Pro-Lock, Nut Type (P/N 1-840022, .5ml tube) on clutch bolt.
