CONTROLS GROUP
-19-
Item Part No. Description Qty.
1 109-8484 Console, Panel W/Decal........................ 1
1:2 109-8483 Decal, Control Panel.............................. 1
1:3 109-7330 Decal, Fuse............................................ 1
2 109-4601 Asm, Choke Cable (34HP Kawasaki)..... 1
109-8165 Asm, Choke Cable (Kohler) ................... 1
109-8167 Asm, Choke Cable (29HP Kawasaki)..... 1
3 109-4602 Asm, Throttle Cable (34HP Kawasaki)... 1
109-8166 Asm, Throttle Cable
(All Units except 34HP Kawasaki).......... 1
4 1-807513 Bolt, Carriage #10-24 x 1/2 .................... 4
5 3296-2 Nut, Nyloc #10-24.................................. 4
Item Part No. Description Qty.
6 107069 Clip........................................................ 4
7 32105-15 Screw, Machine 1/4-20 x 3/4.................. 4
8 109-9341 Console, RH Narrow Asm...................... 1
8:1 104-7201 Nut, Nyloc 1/4-20 Flg............................. 2
8:3 109-9345 Screw, HWH #10-14 x 3/4 TF................ 3
8:4 32105-15 Screw .................................................... 2
9 109-9342 Console.LH Narrow Asm ....................... 1
9:2 109-9345 Screw, HWH #10-14 x 3/4 TF................ 4
10 105-1853 Clamp, Hose.......................................... 1
11 109-9445 Plug, Plastic........................................... 1
