DECK COMPONENTS AND FRONT WEIGHTS
15
Deck Components:
Quantity Included in Each Kit
44” 48” 52” 46” 50” 56”
.
No.
Part No. Description
103-1315 103-1314 109-1185 109-1013 109-1014 109-1015
1 1-653363 Pin, Chute Pivot 1 1 1
103-0453 Pin, Chute Pivot 1 1 1
2 1-806003 Pin, Hair 1 1 1 1 1 1
3 1-323385 Knob, Belt Shield 2 2 2 1 1 1
4 1-653439 Sheave, Blower Drive (52) 1
1-653362 Sheave, Blower Drive (48) 1
1-653309 Sheave, Blower Drive (44) 1
109-1016 Sheave, Blower Drive (46) 1
109-1017 Sheave, Blower Drive (50) 1
109-1018 Sheave, Blower Drive (56) 1
5 3256-27 Washer, 5/8 SAE 1 1 1
6 1-653438 Belt, Blower (46 & 52) 1 1
1-653333 Belt, Blower (48) 1
1-653332 Belt, Blower (44) 1
103-0866 Belt, Blower (50) 1
109-9249 Belt, Blower (56) 1
7 103-1316 Cover, Belt (44 & 48) 1 1
103-1318 Cover, Belt (52) 1
109-1019 Cover, Belt (46) 1
109-1020 Cover, Belt (50) 1
109-1021 Cover, Belt (56) 1
8 322-2 Screw, HH 5/16-18 x 5/8 1 1 1 1 1 1
9 103-1279 Plug 1 1 1 1 1 1
10 109-1022-03 Strap, Weight mount 1 1 1
11 3230-2 Bolt, Carriage 5/16-18 x 1 2 2 2
Front Weight Components: (Used on all units)
12 103-6363 Asm, Weight (103-6364-01) W/Decals 2
13 103-6368-01 Plate, Weight Mounting 1
14 322-5 Screw, HH 5/16-18 x 1 4
6
322-7 Screw, HH 5/16-18 x 1 1/2 4
15 9335124 Hairpin, Cotter 4
6 52” units with standard weight plate bolted to the front of the floor pan only.
