BLOWER ASSEMBLY 46”, 50”, 52” and 56” (cont.)
9
Item
Part No.
Description
Qty.
1 3290-357 Nut, Whizlock 3/8-16..............................3
2 323-11 Screw, HH 3/8-16 x 2 1/4.......................2
3 3256-4 Washer, 3/8 Std.....................................3
4 109-1985 Chute, Blower (46, 50 & 56)...................1
103-4764 Chute, Blower (52).................................1
5 109-1122-01 Bumper..................................................1
6 3290-500 Screw, PPH #10-24 x 5/8.......................4
7 321-3 Screw, HH 1/4-20 x 5/8..........................4
8 32128-33 Nut, Whizlock 1/4-20..............................11
9 3229-11 Bolt, Carriage 1/4-20 x 5/8 .....................3
10 1-803075 Screw, CRTH #10-24 x 3/4 (46,50&56)..3
1-803075 Screw, CRTH #10-24 x 3/4 (52).............5
11 3290-148 Nut, Whizlock #10-24 (46, 50 & 56)........3
3290-148 Nut, Whizlock #10-24 (52)......................5
12 1-803076 Screw, CRTH 1/4-20 x 3/4 .....................2
13 1-653596-03 Plate, Blower Backing............................1
14 1-653443-03 Plate, Filler (52)......................................1
Item
Part No.
Description
Qty.
15 3256-14 Washer, #10 Std....................................4
16 1-653429 Asm, Latch.............................................2
17 109-1024 Asm, Blower (46, 50 & 56) (Includes All
Items From Pg 7 & Items 1-16 & Decals) ...
1
103-0400 Asm, Blower (52) (Includes All
Items From Pg 7 & Items 1-16 & Decals) ...
1
18 3290-500 Screw, PPH #10-24 x 5/8.......................2
19 3296-2 Nut, Nyloc #10-24.................................3
20 3256-14 Washer, #10 Std....................................5
21 109-2041 Tube, Lower (46 & 50)...........................1
109-2040 Tube, Lower (52 & 56)...........................1
22 109-2035 Tube, Upper...........................................1
23 32105-13 Screw, Slotted HH #10-24 x 3/4.............3
24 3229-1 Bolt, Carriage 1/4-20 x 3/4.....................2
25 323-7 Screw, HH 3/8-16 x 1 1/4.......................1
26 103-4752-03 Plate, Reinforcement .............................1
27 114439 Rivet......................................................3
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Exmark black touch up spray paint – gloss black.
Kit 103-0583 is available to repair the welded-on accessory mounting tube on all 44”-72” decks.
