LOWER HOPPER ASSEMBLY
11
Item
Part No.
Description
Qty.
1 109-0329-03 Wld, QDS Frame....................................1
2 103-6294 Pin, Hinge Pivot .....................................2
3 103-6295 Bearing ..................................................2
4 103-4820-03 Plate, Hinge ...........................................2
5 103-4412-03 Plate, Rear.............................................1
6 103-4832 Seal, Door..............................................1
7 103-4834-03 Strap, Hold Down...................................1
8 103-4402 Bearing ..................................................2
9 103-5114-03 Wld, Bellcrank........................................1
10 103-4433 Collar, Shaft...........................................1
11 103-3202 Cap, Tube..............................................2
12 103-8835-03 Wld, Link RH..........................................1
13 103-5111 Wld, Link RH..........................................1
14 103-5112 Wld, Link LH ..........................................1
15 94-8196 Washer, Nylon .......................................6
16 32151-61 Ring, Retaining ......................................6
17 103-4848 Trunnion, Link........................................2
18 103-4424 Arm, Door Linkage.................................2
19 103-4431 Washer ..................................................2
20 103-4415 Bearing, Linkage Pivot...........................2
Item
Part No.
Description
Qty.
21 103-4408-03 Stop, Linkage.........................................2
22 103-7828 Panel, Bagger LH ..................................1
23 103-7829 Panel, Bagger RH..................................1
24 103-5102 Panel, Bagger........................................1
25 107069 Nut, Retainer 1/4-20...............................6
26 3231-4 Bolt Carriage 3/8-16 x 1 1/2...................2
27 3256-4 Washer, 3/8 Std.....................................2
28 3296-59 Nut, Nyloc 3/8-16 Thin...........................2
29 322-5 Screw, HH 5/16-18 x 1...........................4
30 3256-23 Washer, 5/16 SAE.................................22
31 3296-29 Nut, Nyloc 5/16-18.................................12
32 321-4 Screw, HH 1/4-20 x 3/4..........................10
33 3256-22 Washer, 1/4 SAE...................................4
34 32128-33 Nut, Whizlock 1/4-20..............................10
35 3230-5 Bolt, Carriage 5/16-18 x 1 3/4................4
36 3274-1 Screw, SH 3/8-16 x 1 1/4.......................1
37 323-7 Screw, HH 3/8-16 x 1 1/4.......................2
38 3296-39 Nut, Nyloc 3/8-16...................................2
39 3230-2 Bolt, Carriage 5/16-18 x 1......................4
40 114439 Riviet .....................................................14
