48” MOWER DECK
5
Item Part No. Description Qty.
1 109-2601 Deck (116-0617-01)W/Decals
Dogleg & Discharge Deflector................1
2 1-402107-01 Wld, Dogleg Baffle .................................1
3 322-2 Screw, HH 5/16-18 x 5/8........................3
4 32128-20 Nut, Whizlock 5/16-18............................11
5 3296-29 Nut, Nyloc 5/16-18 .................................1
6 323-7 Screw, HH 3/8-16 x 1 1/4 HH.................18
7 3290-357 Nut, Whizlock 3/8-16..............................19
8 98-5975 Washer, Spring Disc 3/8.........................12
9 1-808280 Pin, Clevis 5/16 x 1 ................................1
10 1-303105 Yoke ......................................................1
11 109-0977 Pulley, Idler Pulley..................................2
12 32151-103 E-Ring....................................................1
13 103-6583 Blade, Notched (48")..............................3
103-6581 Blade, Mulching (48").............................3
103-6738 Blade, Low Lift (48”)..............................3
103-1577 Blade, Solid (48”) ..................................3
103-6336 Blade, Extreme (48”)..............................3
14 1-323303 Linkage, Assist Arm ...............................1
15 1-803310 Setscrew, 5/16-18 x 3/8..........................3
16 323-13 Screw, HH 3/8-16 x 2 3/4.......................2
17 3296-42 Nut, Nyloc 1/4-20 ...................................2
18 1-513810 Bushing..................................................4
19■ 103-8387 Asm, Cutter Housing Complete..............3
20 103-8280 Asm, Cutter Housing..............................3
21 302-61 Zerk, 45° 1/4-28.....................................2
22 103-2535 Spacer ...................................................3
23 1-513809 Bearing, Roller.......................................2
24 702809 Screw, HH 3/8-16 x 1 7/8.......................1
25 1-323529 Tube, Spindle.........................................3
26 32120-35 E–Ring...................................................1
27 3296-39 Nut, Nyloc 3/8-16 ...................................18
28 1-807267 Key, 1/4 x 3/16 x 1 1/4 ...........................3
29 1-403183 Sheave, Blade Driven ............................3
30 1-513208 Washer Spring Disc 5/8..........................3
31 1-800861 Screw, HH 5/8-18 x 8.............................3
32 1-323539 Spacer, Blade Drive ...............................12
33 1-323339 Washer..................................................3
34 1-322235 Arm, Assist.............................................1
35 3219-6 Nut, Hex 5/8-18 UNF..............................3
36 1-303434 Bushing, Engagement............................1
37 1-303348 Eye Bolt (Left Hand Thread)...................1
38 1-303236 Turnbuckle Body....................................1
39 1-303238 Eye Bolt (Right Hand Thread) ................1
40 1-323747 Spring, Compression..............................1
41 1-806003 Hairpin, Cotter #2...................................3
42 1-303352 Washer, Spindle.....................................1
43 322-10 Screw, HH 5/16-18 x 2...........................1
44 1-323729 Bearing ..................................................2
45 1-303334 Washer, Spring Disc 5/16.......................1
Item Part No. Description Qty.
46 103-3600 Asm, Engagement Arm W/Bushings......1
47 322-6 Screw, HH 5/16-18 x 1 1/4.....................1
48 302-19 Zerk, 1/4-28 Str......................................1
49 3256-24 Washer, 3/8 SAE...................................2
50 323-20 Screw, HH 3/8-16 x 3 1/4.......................1
51 3296-56 Nut, Nyloc 1/4-20 Thin...........................1
52 109-5151 Deflector, Discharge ..............................1
53 1-403179 Tube, Pivot ............................................1
54 3256-3 Washer, Flat 5/16 Std............................1
55 1-323714 Rod, Brake LH.......................................1
56 1-324372 Asm, Pad/Spring....................................1
57 3256-23 Washer, 5/16 SAE .................................1
58 1-603843 Pulley, Idler............................................1
59 1-403174 Belt, Drive (Main Deck) 48"....................1
60 1-323746 Spacer, Flanged ....................................1
61 1-403184 Bushing .................................................2
62 109-8854 Pin, Chute..............................................1
63 1-323071 Spring....................................................1
64 103-1330 Guard, Bearing Top...............................3
65 103-1238 Asm, Caster/Mount Complete................2
103-2281 Asm, Caster/Mnt Complete, Weighted ...2
66 1-302203 Asm, Caster Whl Support W/Bearings ...2
103-2296 Caster Wheel Support
W/Bearings, Weighted...........................2
67 1-302194-01 Wld, Caster Wheel Support....................2
103-2297-01 Wld, Caster Wheel Support, Weighted...2
68 302-52 Zerk, 1/8 NPT........................................2
69 1-303514 Flange, Thrust Bearing ..........................4
70 1-303314 Spacer, 10” Caster.................................8
71 103-1236 Asm, Caster Wheel................................2
72 1-322145-01 Wld, Caster Fork....................................2
73 321-4 Screw, HH 1/4-20 x 3/4..........................2
74 1-323748 Ring, Push-On 7/16 ...............................1
75 1-323417 Washer, Belt Cover Mount.....................5
76 323-4 Screw, HH 3/8-16 x 3/4..........................8
77 325-20 Screw, HH 1/2-13 x 6.............................2
78 3217-9 Nut, Hex 1/2-13......................................2
79 3253-7 Washer, Lock 1/2...................................2
80 1-513338 Washer, Special.....................................2
81 1-809020 Quick Pin, 10” Caster.............................2
82 1-303537 Stud, Belt Shield (Short) ........................2
83 1-303536 Stud, Belt Shield (Long).........................3
84 1-323385 Knob, Belt Cover....................................5
85 1-404238 Shield (1-402100-01)W/Decals 48”........1
86 1-403188 Spacer, Belt Guide.................................1
87 323-8 Screw, HH 3/8-16 x 1 1/2.......................8
88 1-513547 Spacer, Front Caster..............................2
89 103-2171 Kit, Tire & Wheel Asm W/ Spacer ..........2
90 116-0962 Spring....................................................1
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews.
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N’s MK483.
Models with ECS handles only.
Models with Standard pistol grip handles only.
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & bearings
and spindles & sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-seize.
■ Does not include items #6 and #27.
