ECS UPPER HANDLES and CONTROLS
13
Item Part No. Description Qty.
1 103-1566-03 Wld, Lever, OPC (LH) ............................1
2 1-303365 Bushing, Nylon.......................................2
3 1-803322 Setscrew, 5/16-24 x 5/16........................2
4 103-0769-03 Wld, OPC Rod .......................................1
5 1-303363 Spring, Actuator .....................................1
6 1-303335 Tie, Plastic 7 5/16” ................................1
7 1-807513 Bolt, Carriage 10-24 x 1/2 ......................2
8 3296-2 Nut, Nyloc #10-24 ..................................2
9 109-3958 Cable, Throttle Control ..........................1
10 103-1567-03 Wld, OPC Lever (RH).............................1
11 1-303020 Grip, Lever.............................................1
12 103-1629 Lever, Clutch W/Grip..............................1
13 3296-29 Nut, Nyloc 5/16-18 .................................2
14 3256-4 Washer, 3/8 Std.....................................1
15 103-0027 Spacer ...................................................2
16 1-806003 Cotter, Hairpin........................................2
17 103-1627 Linkage, Upper.......................................1
18 103-1604 Linkage, Wheel Drive.............................2
19 1-543296 Grommet................................................1
20 103-0815 Grip, Handle...........................................2
21 1-303435 Washer, Spring Disc 1/4.........................6
22 103-1631 Latch, Thumb (LH) (Not Shown).............1
103-1630 Latch, Thumb (RH).................................1
23 3296-42 Nut, Nyloc 1/4-20 ...................................1
24 103-0770-03 Wld, Handle ...........................................1
25 1-303088 Clip, Cable .............................................1
26 323-6 Screw, HH 3/8-16 x 1.............................4
27 109-0346 Cap, Fuel Tank ......................................1
28 103-2893 Tank, Fuel W/Fitting...............................1
29 1-633023 Stud.......................................................2
30 1-633349 Spring, Fuel Tank...................................2
31 1-805005 Washer, Lock 5/16 Heavy ......................2
32 3296-47 Nut, Nyloc 5/16-18 .................................2
33 322-3 Screw, HH 5/16-18 x 3/4........................2
34 103-2605 Fitting, Fuel Bulkhead W/Screen............1
35 103-0498 Nut, Ignition Switch ...............................1
36 1-303077 Clamp, Fuel Line ...................................4
37 33114-016 Screw, HH M8-16 x1.25 ........................1
38 1-603770 Valve, Fuel.............................................1
39 1-805004 Washer, Lock 1/4 Heavy........................1
40
Kawasaki
PN 41019-1055 W/6” Fuel Line..............1
Item Part No. Description Qty.
41 103-1610 Harness, Wiring..................................... 1
42 3256-22 Washer, 1/4 SAE................................... 1
43 321-4 Screw, HH 1/4-20 x 3/4.......................... 1
44 1-403121 Switch, On/Off .......................................1
1-603511 Key, Ignition........................................... 1
103-2106 Key, Exmark Logo................................. 1
45 1-633181 Plate, Tapped........................................ 1
46 3296-39 Nut, Nyloc 3/8-16................................... 5
47 3290-500 Screw, PPH #10-24 x 5/8....................... 2
48 1-513051 Switch, Neutral Lockout......................... 1
49 1-323229 Clip, Loom 3/8....................................... 1
50 1-303287 Tie, Plastic 5 1/2”................................... 6
51 1-323430 Module, Wiring Harness......................... 1
52 323-14 Screw, HH 3/8-16 x 3............................. 1
53 322-9 Screw, HH 5/16-18 x 1 3/4..................... 2
54 1-413152 Bearing..................................................4
55 103-2466-03 Lever, Drive (LH)................................... 1
56 3219-3 Nut, Hex 3/8-24 ..................................... 2
57 321-14 Screw, HH 1/4-20 x 2 3/4....................... 2
58 32128-33 Nut, Whizlock 1/4-20.............................. 12
59 103-0464 Pin, Spring 1/8 x 1/2 .............................. 2
60 3256-22 Washer, 1/4 SAE................................... 10
61 103-0235 Screw, 1/4-20 x 1 1/8 W/Nylon............... 2
62 103-2465-03 Lever, Drive (RH)................................... 1
63 3220-3 Nut, Jam 3/8-24.....................................4
64 109-4934 Asm, Console (109-4649-03) 1
W/Decals...............................................
65 3256-23 Washer, 5/16 SAE................................. 4
66 321-3 Screw, HH 1/4-20 x 5/8.......................... 10
67 103-2513 Asm, Drive Lever (RH)........................... 1
103-2514 Asm, Drive Lever (LH)........................... 1
68 103-2463 Joint, .375 Ball End................................ 2
69 103-0489-03 Bracket, OPC Axle................................. 1
70 103-1796 Cable, Choke Push/Pull.........................1
71 103-1797-01 Bracket, Choke Cable............................ 1
72 1-633080 Bushing .................................................1
73 3256-14 Washer, #10 Std.................................... 1
74 109-0293 Hose, Fuel Line 8.5” ..............................1
75 1-413510 Clip, Loom 1/2”...................................... 1
76 109-0306 Hose, Fuel Line 6” ................................1
77 33113-016 Screw, HH M6-16 x 1............................. 1
NOTE: Use dielectric grease on all electrical connections.
Exmark black touch up spray paint – Gloss black
Use Pro-lock (Nut type) Part No. 1-840022 (.5 ml tube) on setscrew threads, thumb latch screws and on fuel tank fitting.
Use Pro-lock (Retaining) Part No. 1-840023 (.5 ml tube) on inside of bore of OPC hub and on fuel tank studs going into
tank.
