32” and 36” MOWER DECK
3
Item Part No. Description Qty.
1 103-2312 Deck (116-0616-01) W/Decals
Dogleg & Discharge Deflector (36")........1
116-0799 Deck (116-0618-01) W/Decals &
Dogleg & Discharge Deflector (32")........1
2 1-302189-01 Wld, Dogleg Baffle .................................1
3 322-2 Screw, HH 5/16-18 x 5/8 ........................7
4 32128-20 Nut, Whizlock 5/16-18............................22
5 103-3600 Asm, Engagement Arm W/Bushings ......1
6 302-52 Zerk, 1/8 NPT Straight ...........................2
7 302-19 Zerk, 1/4-28 Straight ..............................1
8 1-323385 Knob, Belt Cover....................................4
9 1-809020 Quick Pin, 10" Caster.............................2
10 3296-29 Nut, Nyloc 5/16-18 .................................1
11 323-8 Screw, HH 3/8-16 x 1 1/2 .......................8
12 3290-357 Nut, Whizlock 3/8-16..............................16
13 1-323748 Ring, Push-On 7/16................................1
14 98-5975 Washer, Spring Disc 3/8.........................9
15 1-808280 Pin, Clevis 5/16 x 1 ................................1
16 1-303105 Yoke ......................................................1
17 1-806003 Hairpin, Cotter #2...................................3
18 32151-103 E-Ring....................................................1
19 702809 Screw, HH 3/8-16 x 1 7/8 .......................1
20 103-6584 Blade, Notched (36")..............................2
103-6582 Blade, Mulching (36").............................2
103-6580 Blade, Low Lift (36")...............................2
103-1578 Blade, Solid (36") ...................................2
103-6337 Blade, Extreme (36”)..............................2
103-6583 Blade, Notched (32")..............................2
103-6581 Blade, Mulching (32) ..............................2
103-6738 Blade, Low Lift (32")...............................2
103-1577 Blade, Solid (32") ...................................2
103-6336 Blade, Extreme (32”)..............................2
21 1-513338 Washer, Special.....................................2
22 3253-7 Washer, Lock 1/2...................................2
23 3217-9 Nut, Hex 1/2-13......................................2
24 325-20 Screw, HH 1/2-13 x 6.............................2
25 1-303352 Washer, Spindle.....................................1
26 32120-35 E-Ring....................................................1
27 1-323733 Drive Belt (To Blades) 36" Model ...........1
1-323734 Drive Belt (To Blades) 32" Model ...........1
28 1-803310 Setscrew, 5/16-18 x 3/8..........................2
29 322-6 Screw, HH 5/16-18 x 1 1/4.....................9
30 3256-23 Washer, 5/16 SAE..................................1
31 1-303537 Stud, Belt Shield (Short).........................2
32 1-303536 Stud, Belt Shield (Long) .........................2
33 1-324208 Shield (1-302213-01) W/Decals, 36" ......1
1-324194 Shield (1-322149-01) W/Decals, 32" ......1
34 1-323417 Washer, Belt Cover Mount .....................4
35 1-322145-01 Wld, Caster Fork....................................2
36 103-1236 Asm, Caster Wheel Assembly................2
37 109-5151 Deflector, Discharge...............................1
Item Part No. Description Qty.
38 3296-56 Nut, Nyloc 1/4-20 Thin...........................1
39 1-323729 Bearing..................................................2
40 323-4 Screw, HH 3/8-16 x 3/4..........................8
41 1-603843 Pulley, Idler............................................1
42■ 103-8387 Asm, Cutter Housing Complete..............2
43 109-8854 Pin, Chute..............................................1
44 103-8280 Asm, Cutter Housing..............................2
45 302-61 Zerk, 45° 1/4-28.....................................2
46 103-2535 Spacer...................................................2
47 1-403179 Tube, Pivot ............................................1
48 1-303314 Spacer, 10" Caster.................................8
49 1-323529 Tube, Spindle ........................................2
50 321-4 Screw, HH 1/4-20 x 3/4..........................2
51 1-303514 Flange , Thrust Bearing .........................4
52 1-323339 Washer..................................................2
53 1-403183 Sheave, Blade Driven............................2
54 3219-6 Nut, Hex 5/8-18 UNF .............................2
55 1-800861 Screw, HH 5/8-18 x 8............................2
56 1-807267 Key, 1/4 x 3/16 x 1 1/4...........................2
57 1-323539 Spacer, Blade Drive...............................8
58 1-513208 Washer, Spring Disc 5/8........................2
59 1-303434 Bushing, Engagement............................1
60 1-303348 Eye Bolt (Left Hand Thread) ..................1
61 1-303236 Turnbuckle Body....................................1
62 1-303238 Eye Bolt (Right Hand Thread)................1
63 1-322235 Arm, Assist ............................................1
64 322-10 Screw, HH 5/16-18 x 2...........................1
65 1-323303 Linkage, Assist Arm...............................1
66 103-1238 Asm , Caster/Mount Complete...............2
103-2281 Asm, Caster/Mnt Complete, Weighted ...2
67 1-302203 Asm, Caster Whl Support W/Bearings ...2
103-2296 Asm, Caster Wheel Support
W/Bearings, Weighted...........................2
68 1-302194-01 Wld, Caster Wheel Support....................2
103-2297-01 Wld, Caster Wheel Support, Weighted...2
69 1-303334 Washer, Spring Disc 5/16 .....................9
70 1-324372 Asm, Pad/Spring....................................1
71 103-1330 Guard, Bearing Top...............................2
72 3256-3 Washer, 5/16 Std...................................1
73 1-323715 Rod, Brake 36" ......................................1
1-323718 Rod, Brake 32" ......................................1
74 1-323071 Spring....................................................1
75 1-323747 Spring, Compression .............................1
76 1-323746 Spacer, Flanged ....................................1
77 3296-42 Nut, Nyloc 1/4-20...................................2
78 1-513547 Spacer, Front Caster..............................2
79 103-2171 Kit, Tire & Wheel Asm W/ Spacer ..........2
80 1-513809 Roller Bearing........................................1
81 1-513810 Bushing .................................................4
82 116-0962 Spring....................................................1
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews.
Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N’s MK322(32”) or MK362(36”)
Models with ECS handles only.
Models with Standard pistol grip handles only.
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & bearings
and spindles & sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-seize.
■ Does not include items #4, #29, & #69
