Product Overview
Wheel Base: (Center of Caster Tire to
Center of Drive Tire)
44 inch
Deck
48 inch
Deck
52 inch
Deck
60 inch
Deck
49.7 inches
(126.2 cm)
48.7 inches
(123.7 cm)
48.7 inches
(123.7 cm)
49.7 inches
(126.2 cm)
Curb Weight:
44 inch
Deck
48 inch
Deck
52 inch
Deck
60 inch
Deck
Kawasaki
Units
822 lb
(373 kg)
862 lb
(391 kg)
873 lb
(396 kg)
948 lb
(430 kg)
Torque Requirements
Bolt Location
Torque
Blade Drive Sheave
Mounting Nut
130-160 ft-lb (176-217
N-m)
Blade Mounting Bolt
(lubricate with anti-seize)
50-60 ft-lb (68-81 N-m)
Anti-Scalp Roller Nyloc
Nut See Figure 18
27-33 ft-lb (37-45 N-m)
Anti-Scalp Roller Whizlock
Nut See Figure 18
27-33 ft-lb (37-45 N-m)
Engine Mounting Bolts
27-33 ft-lb (37-45 N-m)
Wheel Lug Nuts
70-90 ft-lb (95-122 N-m)
Rollover Protection
System (Roll Bar) 1/2
inch Mounting Bolts
77-95 ft-lb (104-129 N-m)
Clutch Retaining Bolt
(secured with threadlocker)
49-61 ft-lb (66-83 N-m)
Product Overview
Figure 4
1. Rollover Protection
System (ROPS)
5. Motion control levers
2. Engine Controls (right
console)
6. Parking brake
3. Seat belt 7. Height of cut adjustment
4. Fuel cap
18
