MQL • UNIT CONFIGURATION
6
Position: 1 2 3 4567 8 9 10
MQL - Module Size Dim. 02 03 04 06 08 10 12 14 17
H - in (mm) 17-3/8 (441) 17-3/8 (441) 17-3/8 (441) 26-3/8 (670) 26-3/8 (670) 26-3/8 (670) 41-3/16 (1046) 41-3/16 (1046) 41-3/16 (1046)
W - in (mm) 28 (711) 34 (864) 42 (1069) 42 (1069) 46 (1168) 56 (1422) 64 (1626) 68 (1727) 80 (2032)
L - in (mm) 5-1/4 (133) 5-1/4 (133) 5-1/4 (133) 5-1/4 (133) 5-1/4 (133) 5-1/4 (133) 5-1/4 (133) 5-1/4 (133) 5-1/4 (133)
SAM Small Access H - in (mm) 22 (559) 22 (559) 22 (559) 30 (762) 34 (864) 34 (864) 44 (1118) 44 (1118) 44 (1118)
SCM Small Coil W - in (mm) 30 (762) 36 (914) 44 (1118) 44 (1118) 48 (1219) 58 (1473) 66 (1676) 70 (1778) 82 (2083)
SFM Small Flat Filters (2" and/or 4" Cartridge) L - in (mm) 15 (381) 15 (381) 15 (381) 15 (381) 15 (381) 15 (381) 15 (381) 15 (381) 15 (381)
MAM Medium Access H - in (mm) 22 (559) 22 (559) 22 (559) 30 (762) 34 (864) 34 (864) 44 (1118) 44 (1118) 44 (1118)
MCM Medium Coil W - in (mm) 30 (762) 36 (914) 44 (1118) 44 (1118) 48 (1219) 58 (1473) 66 (1676) 70 (1778) 82 (2083)
MFM
Med. INTELLITRAC
®
Mix. Box w/Flat Filters (2")
L - in (mm) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762)
MIM
Med. INTELLITRAC
®
Inlet Plenum w/Flat Filters (2")
MMM Medium Mixing Box with Flat Filters (2")
MRM Medium Inlet Plenum with Flat Filters (2")
MVM Medium V-Bank Filters (2")
HFM Horizontal FC Fan H - in (mm) 22 (559) 22 (559) 22 (559) 30 (762) 34 (864) 34 (864) 44 (1118) 44 (1118) 44 (1118)
HPM Horizontal Plug Fan W - in (mm) 30 (762) 36 (914) 44 (1118) 44 (1118) 48 (1219) 58 (1473) 66 (1676) 70 (1778) 82 (2083)
RFM Return FC Fan L - in (mm) 32 (813) 32 (813) 32 (813) 36 (914) 36 (914) 36 (914) 40 (1016) 40 (1016) 40 (1016)
RPM Return Plug Fan
VCM Vertical Coil
VFM Vertical FC Fan
MBM Medium Face & Bypass H - in (mm) 30 (762) 30 (762) 30 (762) 40 (1016) 46 (1168) 46 (1168) 56 (1422) 58 (1473) 58 (1473)
MTM Medium Tall Coil W - in (mm) 30 (762) 36 (914) 44 (1118) 44 (1118) 48 (1219) 58 (1473) 66 (1676) 70 (1778) 82 (2083)
STM Small Tall Coil L - in (mm) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762)
H - in (mm) 22 (559) 22 (559) 22 (559) 30 (762) 34 (864) 34 (864) 44 (1118) 44 (1118) 44 (1118)
W - in (mm) 30 (762) 36 (914) 44 (1118) 44 (1118) 48 (1219) 58 (1473) 66 (1676) 70 (1778) 82 (2083)
L - in (mm) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762) 30 (762)
LAM Large Access H - in (mm) 22 (559) 22 (559) 22 (559) 30 (762) 34 (864) 34 (864) 44 (1118) 44 (1118) 44 (1118)
LFM
Lg. INTELLITRAC
®
Mix. Box w/V-Bank Filters (2")
W - in (mm) 30 (762) 36 (914) 44 (1118) 44 (1118) 48 (1219) 58 (1473) 66 (1676) 70 (1778) 58 (1473)
LIM
Lg. INTELLITRAC
®
Inlet Plenum w/V-Bank Filters (2")
L - in (mm) 42 (1067) 42 (1067) 42 (1067) 42 (1067) 42 (1067) 42 (1067) 42 (1067) 42 (1067) 42 (1067)
LMM Large Mixing Box with V-Bank Filters (2")
LRM Large Inlet Plenum with V-Bank Filters (2")
LPM Large Discharge Plenum
FCM FC Fan and Coil Combination (Horizontal Only) H - in (mm) 22 (559) 22 (559) 22 (559) 30 (762) 34 (864) 34 (864) 44 (1118) 44 (1118) 44 (1118)
HEM Horizontal Economizer W - in (mm) 30 (762) 36 (914) 44 (1118) 44 (1118) 48 (1219) 58 (1473) 66 (1676) 70 (1778) 82 (2083)
H - in (mm) 13-1/2 (343) 13-1/2 (343) 13-1/2 (343) 18 (457) 18 (457) 18 (457) 21 (533) 21 (533) 21 (533)
W - in (mm) 11-1/2 (292) 11-1/2 (292) 11-1/2 (292) 17 (432) 17 (432) 17 (432) 24 (610) 24 (610) 24 (610)
L - in (mm) 22 (559) 22 (559) 22 (559) 22 (559) 22 (559) 22 (559) 22 (559) 22 (559) 22 (559)
Electric Heat Draw Thru
Electric Heat Blow Thru
External Flat Filters (2")
UNIT CONFIGURATION (IN DIRECTION OF AIRFLOW)
EHD
EHB
EFM
Upper Deck - B
Lower Deck - A
Notes:
1. All dimensions are +
1/4" (6mm). Metric
values are soft
conversions.
2. Section images are for
identification of unit
configuration only.
See individual section
submittal drawings at
www.enviro-tec.com
for details.
3. Certain configuration
rules apply; see cata-
log and selection
program for details.
4. All data subject to
change without
notice.
Fig. 1
Fig. 2
Fig. 2
Fig. 2
Fig. 2
Fig. 3
Fig. 4
Fig. 4
Fig. 5
ENVIRO-TEC
