MQL • FAN PERFORMANCE CURVES
18
MQL08 (Fan 12-12 Class I)
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
1800 2000 2200 2400 2600 2800 3000 3200 3400 3600 3800 4000 4200 4400 4600 4800 5000 5200
CFM
STATIC PRESSURE - INCHES WATER GAUGE
600
800
1000
1200
1400 RPM
3 HP
1/2 HP
3/4 HP
1 HP
1.5 HP
5 HP
2 HP
MQL10 (Fan 15-11 Class I and II)
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
2400 2600 2800 3000 3200 3400 3600 3800 4000 4200 4400 4600 4800 5000 5200 5400 5600 5800
CFM
STATIC PRESSURE - INCHES WATER GAUGE
600
800
1000
1200 RPM
1.5 HP
1 HP
3/4 HP
5 HP
3 HP
2 HP
400
CLASS I
CLASS II
SE = CFM x SP
6362 x BHP
SE = CFM x SP
6362 x BHP
ENVIRO-TEC
