OWNER’S MANUAL
For more information, visit www.desatech.com
PARTS LIST
EL-7
This list contains replaceable parts used in your chainsaw. When ordering parts, be sure to provide the
correct model number (from the model plate), then the part number and description of the desired part.
QTY.
KEY 14" 16"
NO. PART NO. DESCRIPTION 075890L 100860-01
1 097570-01S Guide Bar, 14" 1
__
097572-03S Guide Bar, 16"
__
1
2 091374-02 Saw Chain 1
__
091375-02S Saw Chain
__
1
3 100933-01 Armature Assembly 1 1
4 075676 Sprocket Roller Bearing 1 1
5 076744 Hex-Head Bolt 2 2
6 107512-01 Cap & Bulb Assembly 1 1
7 099829-01 Cord 1 1
8 077399-02 Side Cover, Black 1 1
9 098042-01 Field & Brush Assembly 1 1
10 059606 Drive Gear 1 1
11 107713-01 Internal Gear 1 1
12 106810-01 Sprocket Cover, Black 1 1
13 108626-01 Front Hand Guard 1 1
14 076053 Motor Housing Assembly 1 1
15 097034-02 Housing Assembly, Black 1 1
16 NPC-4C Hex Nut 2 2
17 077115 Adjusting Plate Assembly 1 1
18 079086-02 Oil Reservoir 1 1
19 059046 Pan-Head Tap Screw 6 6
20A 076905 Pan-Head Shoulder Screw 1 1
20B 108120-01 E-Ring 1 1
21 076906 Flat-Head Tap Screw 1 1
22 097403-01 Pan-Head Screw 1 1
23 077143 Sprocket Support 1 1
24 077525S Lock-off Switch 1 1
25 058059 Thrust Washer 1 1
26 079963-04 Scabbard
__
1
27 059045 Pan Head Tap Screw 4 4
PARTS AVAILABLE - NOT SHOWN
100395-01 Cable Tie
__
1
079417-03 Hex Wrench 1 1
079882-09 Hardware Package 1
__
Includes: 2 - NPC-4C Nuts,
2 - 076744 Bolts,
1 - 097403-01 Screw
IMPORTANT: Your chainsaw
is assembled with
EITHER
part 20A
OR part 20B depend-
ing on your saw’s design. See
illustration on previous page
to determine which saw de-
sign you have.
