12
105020
ELECTRIC CHAIN SAW
®
For more information, visit www.desatech.com
OPERATING CHAIN
SAW
Continued
Log Supported On One End
1. Make first cut on underside of log (see
Figure 15). Use top of guide bar to
make this cut. Cut 1/3 through diam-
eter of log. This cut will keep section
from splintering when cut.
2. Make second cut directly above first
cut. Cut down to meet first cut. This
cut will keep log from pinching guide
bar and chain.
Figure 15 - Bucking Log When Log Is
Supported On One End
2nd Cut
1st Cut
Log Supported On Both Ends
1. Make first cut from above log (see Fig-
ure 16). Cut 1/3 through diameter of
log. This cut will keep section from
splintering when cut.
2. Make second cut on underside of log,
directly under first cut. Use top of guide
bar to make this cut. Cut up to meet
first cut. This will keep log from pinch-
ing guide bar and chain.
Figure 16 - Bucking Log When Log Is
Supported On Both Ends
1st Cut
2nd Cut
CLEANING AND
MAINTENANCE
Normal Guide Bar Guide Bar With
Uneven Wear
Guide Bar
Groove
Guide Bar
Figure 17 - Guide Bar Cross Section
Showing Uneven Bar Wear
Keep saw body clean. Use a soft cloth damp-
ened with a mild soap and water mixture.
Wipe saw body to clean.
CARE OF GUIDE BAR
Uneven bar wear causes most guide bar prob-
lems. Incorrect sharpening of chain cutter and
depth gauge settings often cause this. When
bar wears unevenly, it widens guide bar
groove (see Figure 17). This causes chain
clatter and rivet popping. Saw will not cut
straight. Replace guide bar if this occurs.
Inspect guide bar before sharpening chain.
A worn or damaged guide bar is unsafe. A
worn or damaged guide bar will damage
chain. It will also make cutting harder.
WARNING: When cleaning
saw body
• do not submerge saw in any
liquids
• do not use products that con-
tain ammonia, chlorine, or
abrasives
• do not use chlorinated clean-
ing solvents, carbon tetrachlo-
ride, kerosene, or gasoline
WARNING: Cutting edges on
chain are sharp. Use protective
gloves when handling chain.
WARNING: Unplug chain saw
from power source before servic-
ing. Severe injury or death could
occur from electrical shock or
body contact with moving chain.
CLEANING SAW BODY
NOTICE: Below are instructions
for servicing your chain saw. Any
servicing not mentioned below
should be done by an authorized
service person.
