Normal Removal
& Installation
Collector Removal
1. Unhook strap (P, Figure 17) from pin (O). Slide
middle tube (H) into upper tube (G) and remove
middle tube (H). Remove upper tube (G) from
cover (B).
2. Lift up cover (B) remove and empty bags (E).
3. Unhook strap (I) from locknut and capscrew (K).
Remove lower chute (N) from mounting plate (L).
See that the discharge deflector (J) returns to the
DOWN position.
4. Remove hair pin (D) and pins (C) then remove
cover (B).
Note: To prevent loss of parts, reinstall pins (C) and
hair pins (D) in support assembly hinge pivots (E,
Figure 17).
5. Remove hitch support assembly (A) from rear
frame spacers (S).
WARNING
OPERATION WITHOUT BAGGER
For operation without bagger, the mower
deflector MUST be properly installed in the
down position and retained by the spring latch.
