6.1 S1-3 Pump 6. Parts list
Parts List
Pos. Description
1 Gearcase - universal mounting
2 Dowel
3 Stud, rotorcase retention
4 Nut, rotorcase retention
4A Washer, rotorcase retention
5 Cover, gearcase
6 Screw, gearcase cover
7 Lip seal, drive end
8 Shim
8A Shim retainer
8B Shim retainer screws
9 Rotorcase
10 Stud, rotorcase/cover retention
11 ‘O’ Ring, cover
12 Cover, rotorcase
13 Dome nut, rotorcase cover
14 Retainer, seal
15 Screw, seal retainer
16 Lip seal, gland end
17 Rotors
18 ‘O’ Ring, rotor sealing shaft end
20 ‘O’ Ring, rotor sealing nut end
22 Nut, rotor retention
23 Key
24 Shaft, drive
25 Shaft, auxiliary
26 Bearing, rear
27 Spacer, shaft abutment
30 Nut, bearing
31 Bearing, front
32 Spacer, bearing
36 Timing gear
38 Torque locking element
39 Clamp plate
40 Screw, clamp plate
45 Drain plug
46 Sight glass
46A Washer, sight glass
47 Filler plug
48 Plug
49 Blanking plug
50 Gland guard
51 Screw, gland guard
52 Washer, gland guard
53 Washer, gland guard
54 Foot, vertical port
55 Foot gasket, vertical port
56 Foot, horizontal port
57 Foot gasket, horizontal port
58 Bolt, Foot
