P/N: 4PFX020-010
©2004 Paxton Automotive Corp.
All Rights Reserved, Intl. Copr. Secured
28JUL04 v1.2(Univ.SBF Carb-4PFX v1.2)
Congratulations! You have purchased the finest street
Supercharger available. The centerpiece of this kit is the
highly efficient and reliable Paxton Automotive Corp.
NOVI-1200 supercharger. A mechanically driven (by
belt) centrifugal blower (supercharger).
This kit comes with all of the parts you’ll need for a
successful installation. The operations required have
been grouped in order of sequence. Photos and drawings
accompany the text, allowing quick orientation and parts
identification.
Installation requires a selection of tools which are listed
in a table at the end of this section.
We also suggest that you obtain a shop manual and
become familiar with the details of your cars systems.
For best results follow the instructions closely and in
sequence. The average installation time for this kit is 6
hours. Your actual installation time will depend on skill
level and working conditions. The estimate does not
include time for initial vehicle inspection, cleaning, fine
tuning or troubleshooting. Before even picking up a
wrench, read this entire manual. We are available for
technical assistance at (805) 604-1336, 8am-4:30pm
pacific time.
After reading the manual, verify that all major assembly
groups are present in the main kit box. You should have
ample space to layout the components. As you remove a
box or bag from the main kit, note the identification
label and compare it with the parts list. Please check the
box for small parts.
Paxton makes every effort to insure that all parts are
included in the box. However, if you discover any
missing or mislabeled parts, please contact Paxton by
phone for service.
*** WARNING ***
DO NOT attempt installation if any part(s) are missing
from this kit. Failure to contact Paxton prior to begin-
ning installation will result in a charge for any missing
parts.
Before starting the installation, we suggest your engine
compartment be clean. You can clean the engine and
compartment with a pressure washer (such as those used
at self serve car washes) and a safe-for-aluminum
Section 1
INTRODUCTION
cleaner/degreaser. Cover the distributor with a plastic
bag to prevent water from entering.
*** CAUTION ***
We do not recommend proceeding with the kit installa-
tion unless your vehicle is within normal operating
parameters.
You are undoubtedly enthusiastic about getting started
on your project, but take just a little more time to insure
that your safety is not jeopardized. A moment’s lack of
attention can result in an accident, as can failure to
observe certain simple safety precautions. The possibil-
ity of an accident will always exist, and the following
points should not be considered a comprehensive list of
all dangers. Rather, they are intended to make you aware
of the risk and to encourage a safety conscious approach
to all work you do on your vehicle.
We look forward to hearing from you, particularly if you
have any comments or suggestions regarding this
manual at:
(805) 604-1336
Paxton Automotive Corporation
1300 Beacon Place
Oxnard, CA 93033
E-mail Address info@paxtonauto.com.
*** NOTE ***
Throughout these procedures the word “discard” is
used periodically in relationship to items that will no
longer be utilized in conjunction with the supercharger
installation. It is recommended that these items be
saved for future use should it become necessary.
1-1
