6.2 Sound
Allows user to shut off non-safety related operating sounds.
6.3 Mowing
Allows user to turn blade operation off, preventing blade operation during automatic operation
and manual mowing.
6.4 Language
Allows the user the option of viewing the LCD text in several different language versions.
6.5 Work Time
Allows the user the option of setting the operating time from the ‘MAX’ default setting to times
ranging from 20 minutes up to 2 hours. Figure 6.5 This option is available for up to 4 different
zones, A, B, C or D. Having four different zones can allow you to set operating time for several
different zones that are of varying sizes, not requiring the same operating time for mowing.
6.6 Wide Scan
Wide scan provides the Robomower a secondary navigation technique which can prove to be
beneficial in some lawns. Wide scan will increase the distance between subsequent legs of
mowing after each movement off of the perimeter wire. If it appears that the Robomower is
simply driving along the same path back and forth, activate wide scan.
6.7 Learn Edge
This menu option can only be seen when the Manual Controller is in the holder and flush with the
mower top. ‘Learn Edge’ gives you the ability to have the Robomower learn the distance around
the perimeter during edge. Figure 6.6
x Position the Robomower to start edge mowing and place the Manual Controller in the
holder
x Follow the steps described in Figure 6.6 to begin the process
x ‘Learn Edge’ is specific to each zone, so be sure you have selected the correct zone
where you want the edge learned
Zone A MAX
Press GO
Scroll to select
different zones.
Zone A MAX
GO to Confirm
Scroll to select different operating
times. Times range from: None =
(zero time) to 2 hours to ‘MAX’
Figure 6.5
Chapter 6
Page 27
