Specications
– 60 inch Deck: 20.50 inches (52.1 cm)
– 72 inch Deck: 24.50 inches (62.2 cm)
• Blade Spindles: Solid steel spindles with 1 3/4
inch (4.45 cm) I.D. bearings.
• Deck Drive: “B”-Section belt from jackshaft on
deck to blade spindles.
• Deck: Full oating deck is attached to out-front
support frame, removable for service. Six
anti-scalp rollers provide maximum turf
protection. Deck design allows for bagging,
mulching or side discharge.
• Deck Depth:
– 52 inch Deck: 5.5 inches (14.0 cm)
– 60 inch Deck: 5.5 inches (14.0 cm)
– 72 inch Deck: 5.5 inches (14.0 cm)
• Cutting Height Adjustment: Adjusts from 1 1/2
inches (3.8 cm) to 5 inches (12.7 cm) innitely
variable.
• Mulching Kit: Optional
• Bagger: Optional
Dimensions
Overall Width:
52 inch
Deck
60 inch
Deck
72 inch
Deck
Without
Deck
49.0 inches
(124.5 cm)
49.0 inches
(124.5 cm)
53.0 inches
(135 cm)
Deector
Up
53.3 inches
(135.4 cm)
61.4 inches
(156 cm)
73.4 inches
(186 cm)
Deector
Down
64.0 inches
(163 cm)
72.0 inches
(183 cm)
84.3 inches
(214 cm)
Overall Length:
23HP Kohler 27HP Kohler &
31HP Briggs &
Stratton
Without deck
and oor pan
folded
80.4 inches
(204.2 cm)
82.3 inches
(209.0 cm)
52 inch Deck 112.4 inches
(285.5 cm)
114.3 inches
(290.3 cm)
23HP Kohler 27HP Kohler &
31HP Briggs &
Stratton
60 inch Deck 112.4 inches
(285.5 cm)
114.3 inches
(290.3 cm)
72 inch Deck 114.3 inches
(290.3 cm)
Overall Height:
Roll Bar - Up Roll Bar - Down
69.2 inches (175.8 cm) 50.7 inches (128.8 cm)
Tread Width: (Center to Center of
Tires, Widthwise)
27HP Kohler & 31 HP Briggs & Stratton Units
52 inch Deck 60 inch Deck 72 inch Deck
41.4 inches
(105.2 cm)
41.4 inches
(105.2 cm)
45.4 inches
(115.3 cm)
23HP Kohler Units
52 inch Deck 60 inch Deck 72 inch Deck
38.9 inches
(98.8 cm)
38.9 inches
(98.8 cm)
Wheel Base: (Center of Caster Tire to
Center of Drive Tire)
• 27HP Kohler & 31HP Briggs & Stratton Units:
51.2 inches (130.0 cm)
• 23HP Kohler Units: 54.1 in (137.4 cm)
Minimum Turning Radius
• 27HP Kohler & 31HP Briggs & Stratton Units:
55.25 inches (140.3 cm)
• 23HP Kohler Units: 56.3 in (143.0 cm)
Curb Weight:
Without deck 911 lb (413 kg)
52 inch Deck
1303 lb (591 kg)
60 inch Deck
1348 lb (611 kg)
72 inch Deck
1397 lb (634 kg)
16
