Specications
Tires & Wheels
Drive
Pneumatic (Air lled)
Quantity
2
Tread
“Multi-Trac C/S”
Size 24 x 12.00-12
Ply Rating
4
Pressure
13 psi (90 kPa)
Front Caster
Semi-Pneumatic
Model LZAS-LP LZAS-LP LZZ-LP
Deck Size
60
72
60
Quantity
2 2 2
Tread
Smooth Smooth Smooth
Size 13 x 5.00-6 13 x 6.50-6 13 x 6.50-6
Ply Rating
— — —
Pressure
— — —
Cutting Deck
• Cutting Width:
– 60 inch Deck: (152.4 cm)
– 72 inch Deck: (182.9 cm)
• Discharge: Side
• Blade Size: (3 ea.)
– 60 inch Deck: 20.50 inches (52.1 cm)
– 72 inch Deck: 24.50 inches (62.2 cm)
• Blade Spindles:
– LZZ-LP Units: Solid steel spindles with 1.18
inch (30 mm) I.D. bearings.
– LZAS-LP Units: Solid steel spindles with 1.00
inch (25 mm) I.D. bearings.
• Deck Drive:
Electric clutch. Shaft diameter 1.125 inches (2.86
cm)
60 and 72 inch Decks: 5V Section belt with
self-tensioning idler.
• Deck:
Full oating deck is attached to out-front support
frame. Anti-scalp rollers provide maximum turf
protection. Deck design allows for bagging,
mulching or side discharge.
– 60 inch Deck: 4 anti-scalp rollers
– 72 inch Deck: 4 anti-scalp rollers
• Deck Depth:
– 60 inch Deck: 5.5 inches (14 cm)
– 72 inch Deck: 5.5 inches (14 cm)
• Cutting Height Adjustment:
Foot activated lever is used to adjust the cutting
height from 1 inch (2.5 cm) to 5 1/2 inches (14
cm) in 1/4 inch (6.4 mm) increments.
• Mulching Kit: Optional.
Dimensions
Overall Width:
60 inch Deck 72 inch Deck
Without Deck 53.0 inches
(134.6 cm)
59.1 inches
(150.1 cm)
Deector Up 62.5 inches
(158.8 cm)
73.5 inches
(186.7 cm)
Deector Down 72.8 inches
(184.9 cm)
84.9 inches
(215.6 cm)
Overall Length:
60 inch Deck 72 inch Deck
Roll Bar - Up 83.1 inches
(211.1 cm)
86.1 inches
(218.7 cm)
Roll Bar - Down 84.8 inches
(215.4 cm)
87.8 inches
(223.0 cm)
Overall Height:
Roll Bar - Up Roll Bar - Down
70.5 inches (179.1 cm) 46.8 inches (118.9 cm)
