Table 29: Connection Object 0x05 — Instance 1 (Explicit Connection)
Table 30: Connection Object 0x05 — Instance 2 (I/O Message)
Attribute Access Data Type Name Value
1 Get USINT State 0 = nonexistent
1 = configured
3 = established
4 = timed out
2 Get USINT Instance Type 0 = Explicit
3 Get BYTE Transport Class Trigger 131 [0x83]
4 Get UINT Produced Connection Id 10[MAC ID]011
5 Get UINT Consumed Connection Id 10[MAC ID]100
6 Get BYTE Initial Comm Characteristics 33 [0x21]
7 Get UINT Produced Connection Size 37
8 Get UINT Consumed Connection Size 37
9 Get/Set UINT Expected Packet Rate Timer Resolution of 10 mSec.
12 Get USINT Watchdog Timeout Action 1 = Auto Delete
Attribute Access Data Type Name Value
1 Get USINT State 0 = nonexistent
1 = configured
3 = established
4 = timed out
2 Get USINT Instance Type 1 = I/O Message
3 Get BYTE Transport Class Trigger 131 [0x83]
4 Get UINT Produced Connection Id 01111[MAC ID]
5 Get UINT Consumed Connection Id 10[MAC ID]101
6 Get BYTE Initial Comm Characteristics 1 [0x01]
7 Get UINT Produced Connection Size 1 – 7
8 Get UINT Consumed Connection Size 1
9 Get UINT Expected Packet Rate Timer Resolution of 10 mSec.
12 Get USINT Watchdog Timeout Action 1 = Auto Delete
14 Get/Set EPATH Produced Connection Path 20 04 24 XX 30 03
XX = Instance
16 Get/Set EPATH Consumed Connection Path 20 04 24 XX 30 03
XX = Instance
100 Get/Set USINT Production ID (Input Assembly) See DeviceNet I/O Assemblies,
Page 39
101 Get/Set USINT Consumption ID (Output Assembly) See DeviceNet I/O Assemblies,
Page 39
