28
English
To Remove Battery Pack from Radio
1. Pivot the locking tab off of the back of the battery pack to
unlock.
2. Lift the bottom of the battery pack slightly to remove it
from the radio housing.
3. Pull battery pack out of the radio housing.
NOTE
The NiMH battery pack can also be charged in the
battery charger without being installed in the radio.
Insert the spacer into the battery charger to support the
battery pack during this charging process. Follow the
same procedures in “Initial Charge” to charge the
battery pack.
NOTICE
NiMH batteries are toxic. Please dispose of properly.
Some marine suppliers accept old battery packs for
recycling and some municipal waste disposal agencies
have special provisions for battery disposal.
Alkaline Batteries
An optional alkaline battery tray (P/N CM 110-011) can be
purchased for this radio. The alkaline battery tray acts as a
backup or “Emergency” power source should the battery
pack run low on power and needs to be recharged. The radio
will transmit at full power when using six (6) new AA alkaline
batteries.
WARNING
Never attempt to recharge alkaline batteries. They are
not made to be recharged, and should be disposed of
in a proper manner.
Batteries and Charger
Installation
Locking Tab
Alkaline Battery Tray
Battery Pack Charging Only
AA Alkaline batteries not
included
