xiii
IEEE 1394 LSI
®
L-FW3227 controller supports 2 x IEEE 1394a ports
(one at midboard; one at back panel)
USB 10 x USB 2.0 ports (4 ports at mid-board, 6 ports at back
panel)
ASUS Unique features ASUS Power Saving Solution:
- ASUS EPU-Six Engine
- ASUS Xtreme 16-Phase Power Design
- ASUS AI Nap
ASUS AI Life Features:
- ASUS Express Gate SSD
- ASUS AI Direct Llink
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Heat-pipe solution
- ASUS Fanless Design: Stack Cool 2
- ASUS Fan Xpert
ASUS EZ DIY:
- ASUS Drive Xpert
- ASUS DieHard BIOS
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS O.C. Prole
- ASUS EZ Flash 2
ASUS Stylish Features ASUS MyLogo3™
ASUS Exclusive
Overclocking Features
ASUS AI Booster utility
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.00625V
increment
- vDIMM: 64-step DRAM voltage control
- vChipset (N.B.): 48-step chipset voltage control
- vCPU PLL: 64-step CPU PLL voltage control
- vVTT_CPU: 40-step Hyper Transport voltage control
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz up to 800MHz at 1MHz
increment
- PCI Express frequency tuning from 100MHz up to
180MHz at 1MHz increment
Overclocking Protection:
- ASUS C.P.R.(CPU Parameter Recall)
(continued on the next page)
P5Q Deluxe specications summary
