18
CONTROLS
2. Parking Brake
The parking brake is found on the left of the
machine. Pull the lever backward to activate
the brake and forward to release it.
Tracking
If the mower is not tracking straight, check
the air pressure in both rear tires.
Recommended air pressure is 15 psi. (1 bar)
Tracking must be checked on a flat and level
concrete or blacktop surface. If the unit still
does not track straight contact your Yazoo/
Kees workshop for adjustments.
3. Fuel Shut Off Valve
The fuel shut off valve is located under the
fuel tank. The valve has two positions;
ON and OFF.
4. Seat adjustment bolts
With the machine off remove the two bolts
holding the seat pan down and flip the seat
forward.
The seat can be adjusted lengthways. When
making adjustments, loosen the four bolts
under the seat pan, after which the seat can
be moved backward or forward.
Once the seat is adjusted to your liking. Flip
the seat back down and rebolt the seat pan to
the frame.
IMPORTANT INFORMATION
The machine must be stopped before
activating the parking brake.
8011-711
Parking brake not activated
8011-712
Fuel shut off valve in OFF position
CZ-1
Lengthways adjustment
