Yazoo/Kees ZCBI48181 Lawn Mower User Manual



24
IMPORTANT: SPECIAL BLADE BOLT IS HEAT
TREATED.
CUSTOMER RESPONSIBILITIES
FIGURE 8
TO SHARPEN BLADE (See Fig. 9)
Care should be taken to keep the blade bal-
anced. An unbalanced blade will cause exces-
sive vibration and eventual damage to mower
and engine.
The blade can be sharpened with a file or
on a grinding wheel. Do not attempt to
sharpen while on the mower.
To check blade balance, you will need a
5/8" diameter steel bolt, pin, or a cone
balancer. (When using a cone balancer,
follow the instructions supplied with
balancer.)
NOTE: Do not use a nail for balancing the blade.
The lobes of the center hole may appear to be
centered, but are not.
Slide blade on to an un-threaded portion
of the steel bolt or pin and hold the bolt or
pin parallel with the ground. If the blade
is balanced, it should remain in a
horizontal position. If either end of the
blade moves downward, sharpen the
heavy end until the blade is balanced.
FIGURE 9
BATTERY
Your mower is equipped with a maintenance
free battery and does not need servicing.
However, periodic charging of the battery with an
automotive type battery charger will extend its
life.
Keep battery and terminals clean.
Keep battery bolts tight.
Recharge at 6-10 amperes for 1 hour
BLADE BOLT
(SPECIAL)
BLADE
CENTER
HOLE
STAR
CUTTER
HOUSING
CENTER HOLE
5/8" BOLT
OR PIN
BLADE
IMPORTANT: TO ENSURE PROPER ASSEMBLY,
CENTER HOLE IN BLADE MUST ALIGN WITH
STAR ON CUTTER HOUSING.
Install and tighten blade bolt securely
(45-55 ft./lbs. torque).
WARNING
When it is necessary to raise the
mower for any repair or service, use
jackstands to provide adequate sup-
port. DO NOT rely on hydraulic or me-
chanical jacks
