ITEM LOCATION LUBRICATION NO.
NO. TYPE PLACES
ITEM LOCATION LUBRICATION NO.
NO. TYPE PLACES
40
Beginning S/N 125598
Effective Date 11-18-13
Use only genuine Walker
®
replacement parts.
LUBRICATION POINTS
Lubrication Points
1 Steering Lever Pivot Grease 4
2 Body Hinge Point Oil 2
3 Deck-to-PTO Coupling Grease 1
(Grease Spline Slide Area)
4 FSC Actuator Rod Pivot Pins Oil 2
5 (FSC) Friction Body Pivot Grease 1
6 FSC Lever Pivot Grease 1
7 FSC Lever Fork Grease 1
(Grease Slide Area)
8 Deck Support Arm Pivot Grease 2
9 Universal Joint Tube Assembly Grease* 1
10 Parking Brake Lever Grease 1
11 Universal Joint Quick Connect Grease 1
Spline (Grease Slide Area)
12 Gear Axle Oil** 2
13 Belt Tightener Pivot, Grease 1
Jackshaft Drive
14 PTO Clutch Lever Pivot Grease 1
15 Clutch Actuator Push Rod Grease 2
16 Belt Tightener Pivot, Grease 1
PTO Clutch
17 Brake Actuator Rod and Brake Oil 3
Band Pivot Pins (Clevis)
18 Brake Actuator Pivot Grease 1
19 Throttle Control Cable Ends Oil 2
20 Catcher Hinge Point Oil 2
21 Rear Wheel Bearings Grease 2
22 Engine Oil Oil** 1
23 Belt Tightener Pivot, Grease 1
Blower Drive (GHS Model Only)
24 Belt Tightener Pivot, Grease 1
Ground Drive
25 PTO Gearbox Dipstick Oil** 1
26 Hydrostatic Drive Oil** 2
27 Throttle Control Pivot Oil 1
* Grease every eight (8) hours.
** Refer to MT Operator’s Manual for procedure for
checking and changing oil in Engine Crankcase, Hydrostatic
Transmissions and Gear Axles.
NOTE: See Model MT Operator’s Manual (P/N 8000-17)
for proper lubrication intervals.
