ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
32
Beginning S/N 125598
Effective Date 11-18-13
Use only genuine Walker
®
replacement parts.
INSTRUMENT PANEL ASSEMBLY
Instrument Panel Assembly
1 7307-2 Instrument Panel Cover (Optional) **
8306-5 Instrument Panel Assembly 1
(Includes Items # 2-12, 14, 19, 21, 29,
F228, F250, F251, F349 & F448)
2 7307-7 Panel Frame 1
3 8820-4 Panel Faceplate 1
4 7386 Panel Gasket 1
5 8996-2 Red Indicator Light Assembly 2
6 6942 Relay Switch (30/40 Amp) NC 2
(Includes Items # 27 & 28)
7 7941-3 Boot, Circuit Breaker 1
8 7941-5 Circuit Breaker (7 Amp) 1
9 8997 Voltmeter Gauge 1
10 5995-2 Switch Boot 1
11 5995 Toggle Switch (Off-On) 1
12 8990-1 Hourmeter (Global) 1
13 5975-1 Cable Tie (18# x 3-3/4") 2
14 8945-3 Wire Harness, Instrument Panel 1
15 8996-4 Red Indicator Lens 2
16 8996-3 Indicator Bulb *
(Replacement for P/N 8996-2)
17 8960-3 Key Set W/Umbrella *
18 7854 Plastic Tip, Red 1
19 8960-15 Ignition Switch (with Keys) 1
(Includes Items # 17, 18 & F349)
20 8996-6 Amber Indicator Lens 1
21 8996-10 Amber Indicator Light Assembly 1
(Includes Items # 16 & 20)
22 7307-1 Shock Mount (1.0 x .25) 3
23 7391 Panel Box Mount Plate 2
24 8385 Panel Box W/Graphic 1
25 7977-1 Grommet (1/8 x 1-1/16) 1
26 7307-16 Lining, Panel Box (1/8) 1
27 6941-6 Relay Switch (30/40 Amp) *
28 6941-7 Relay Mount *
29 8536 Warning Horn 1
Fasteners
F004 1/4-20 Keps Nut 6
F228 #6 x 5/8 PPHSMS, SS 8
F238 J Clip, Instrument Panel 8
F250 6-32 x 1/2 PPHMS 1
F251 6-32 Keps Nut 2
F349 Washer .835 ID, 1.122 OD, SS 1
F448 6-32 x 5/16 PPHMS 1
* Service Part Only
** May be ordered as an option. Contact your Walker dealer.
NOTE: Refer to ELECTRICAL CONNECTORS, Page 38 for identi-
cationofallElectricalWiringServiceParts.
