48
Use only genuine Walker
®
replacement parts. Effective Date 07-01-06
ITEM LOCATION LUBRICATION NO.
NO. TYPE PLACES
ITEM LOCATION LUBRICATION NO.
NO. TYPE PLACES
LUBRICATION POINTS
36", 42", 48" & 56" Assemblies
1 Deck Caster Wheel Fork Pivot Grease 2
2 Blade Drive Gearbox Oil
* 2
3 Tee Gearbox, Deck Oil
* 1
4 Deck Caster Wheel Bearing Grease 2
5 Universal Joint Shaft Assembly Grease
** 1
6 Pivot Assembly, Tilt-Up Deck Grease 4
7 Deck Support Arm Socket Grease 2
DSD52 & DSD62 Assemblies
1 Deck Caster Wheel Fork Pivot Grease 2
4 Deck Caster Wheel Bearing Grease 2
5 Universal Joint Shaft Assembly Grease
** 2
6 Pivot Assembly, Tilt-Up Deck Grease 4
7 Deck Support Arm Socket Grease 2
8 Idler Arm, 2-Hole Grease 1
9 Blade Spindle Grease 3
10 Right Angle Gearbox Oil
*** 1
11 Dolly Wheel Retract Oil 1
Lever and Linkage
12 Dolly Wheel Pivot Grease 1
DSD74 Assemblies
1 Deck Caster Wheel Fork Pivot Grease 2
2 Blade Drive Gearbox Oil
* 4
3 Tee Gearbox, Deck Oil
* 1
4 Deck Caster Wheel Bearing Grease 2
5 Universal Joint Shaft Assembly Grease
** 1
6 Pivot Assembly, Tilt-Up Deck Grease 4
7 Deck Support Arm Socket Grease 2
14 Rear Deck Caster Wheel Axle Grease 2
* Gearboxes are permanently lubricated and sealed requiring
no scheduled lubrication. Oil level should be checked only
when an oil leak is noted.
** Grease every eight (8) hours.
*** Check oil level every 100 hours. Refer to OWNER’S
MANUAL for Lubrication Instructions.
NOTE: Exact location of some Lubrication Points may vary slightly
from those shown in the illustration. Decks shown in the
illustration are for reference only; for further information on
location of parts not shown here, refer to the parts listings
for individual Carrier Frames and Deck Assemblies.
