Walker 36-inch Lawn Mower User Manual



12
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
Use only genuine Walker
®
replacement parts. Effective Date 07-01-06
DGHS42 DECK ASSEMBLY (P/N 5705)
INCL. OPTIONAL HEAVY DUTY GEARBOXES
Gearbox and Drive Components
1 8618-1 Cover, PTO Shaft Guard 1
2 8619 PTO Shaft Guard 1
8618 PTO Shaft Guard Assembly
*
(Includes Items # 1, 2, F002 & F025)
3 5285-15 U-Joint Shaft Assy, 90 Degree, Spline 1
(Includes Items # 26, F069 & F295)
4 7275-16 U-Joint Tube Assy, Spline 1
5 5275-15 U-Joint Tube Assy (9.5" OAL), Spline 1
(Includes Item # F076)
6 5704-50 Gearbox and Tube Assembly 1
(Includes Items # 12-21, F124, F136,
F179 & F211)
5704-8 Heavy Duty Gearbox and Tube Assembly
**
(Includes Items # 12-16, 18-21, F136,
F179 & F211)
7 5794 Discharge Chute (6-1/2 Diameter) 1
(Includes Items # 9, 11, F223 & F224)
5794-1 Discharge Chute Assembly with
Spring Mount
*
(Includes Items # 6, 7, 10, 11, F223 & F224)
8 8678 Spring Mount, Chute 1
9 8677 Extension Spring (1 x 6-1/16) 1
10 5726 Chute Hinge (2 x 8) 1
11 5755 Chute Lower Lip 1
12 6054 Spline Coupling 4
13 P007 Gasket, Cap (Peerless #788030) 4
14 5063 Gearbox Connector Tube (8-5/8) 1
15 6732-3 Connecting Shaft (6-1/4) 1
16 5052-1 Gearbox (LH Rotation) 2
5052-5 Heavy Duty Gearbox (LH Rotation)
**
17 5706-4 Seal Protector Plate 2
18 5704-1 Gearbox Cover Support 2
19 5051-16 Tee Gearbox, Shear 1
5051-6 Heavy Duty Tee Gearbox, Shear
**
20 6732-1 Connecting Shaft (2") 1
21 5062 Gearbox Connector Tube (4-3/8) 1
22 5052-3 1.375 x .750 x .187 Washer 4
23 5747-11 Rubber Mat (3 x 6) 2
24 5785-5 42" Gearbox Cover (Includes Item # 23) 1
25 5830 Grease Fitting 1
26 8067-13 Shear Pin w/Cotter (Set of 5)
*
(Includes Item # F069)
Deck Housing Components
27 8670 Tilt-Up Hook 1
28 5162-11 Roller Wheel (5" Poly) 2
(Includes Item # F059)
29 8490 Roller Wheel Axle Bolt 2
30 NS Deck Serial Number Plate 1
31 5705-3 Blade, 22" (RH Rotation) 1
32 5706 Blade Hub & Trash Guard 2
33 5705-4 Blade, 22" (LH Rotation) 1
5705-8 42 GHS Blade Set with Hubs
*
(Includes Items # 31-33, F002 & F202)
34 8735-10 Rubber Mat (5 x 6) 2
35 7775-1 Hitch Pin, LH (Silver) #6 2
36 8788-1 Rubber Mat (1 x 2) 1
37 5704-4 42 GHS Deck Housing 1
(Includes Items # 34 & 36)
38 7775-2 Hitch Pin, RH (Gold) #6 2
39 5727-1 Washer Shim (5/8 ID) 4
Fasteners
F002 10-24 Keps Nut 9
F004 1/4-20 Keps Nut 2
F005 1/4-20 ESNA Nut 2
F013 3/8-16 Whiz Locknut 6
F018 5/8-18 Hex Nut 2
F025 10-24 x 3/8 PPHMS 2
F029 1/4-20 x 1/2 Hex Bolt 2
F036 1/4-20 x 1/2 SBH Screw 2
F038 3/8-16 x 1 Hex Bolt 4
***
F039 3/8-16 x 1-1/4 Hex Bolt 4
F050 1/4 SAE Washer 4
F055 5/8 SAE Washer 2
F056 5/8 Split Lock Washer 2
F059 3/8 Wave Spring Washer 2
F069 3/32 x 1/2 Cotter Pin 1
F076 3/8-16 x 5/8 SQH Set Screw
*
F087 #10 x 7/8 Fender Washer 2
F124 10-32 x 3/8 Taptite Machine Screw 6
F129 10-24 x 1/2 PTHMS 3
F136 AN960C416L Washer 20
F179 1/4-20 x 1 Hex Bolt 4
F202 10-24 x 5/8 SHC Screw, GR5 SS 4
F206 #2 x 3/16 Drive Pin 2
F211 1/4-20 x 7/8 Hex Bolt 16
F223 3/16 x 5/16 Semi-Tube Rivet
*
F224 3/16 x 7/16 Semi-Tube Rivet *
F229 C-Clip (13/16) 4
F246 1/4-20 x 1/2 PTHMS 2
F278 3/8 Split Lock Washer 4
***
F295 3/16 x 1-1/2 Split Spring Pin 1
F403 1/4-20 x 1/2 PTHMS SS 2
* Service Part Only
** Item(s) used on the Heavy Duty version of standard gear-
boxes. The Heavy Duty cast iron gearboxes are interchange-
able with Standard aluminum gearboxes.
*** Used on Heavy Duty gearbox configuration.
NOTE: Order Item # 4 to use the splined deck PTO shaft with
Model MT, MD and MC.
NOTE: Order Item # 5 to use the splined deck PTO shaft with
Model MS.
