WIRING HARNESS TO ENGINE PLUG CONNECTION
Gray wire goes to carburetor fuel solenoid
Green wire goes to oil pressure switch
Black wire goes to engine ignition module
Red wire goes to engine charging system
Green wire goes to hour meter
Red wire goes to terminal on solenoid
with the positive battery cable.
Black wire goes to the ignition switch.
Gray wire goes to hour meter
WIRING HARNESS PLUG TO ENGINE
Gray wire goes to hour meter
Green wire goes to hour meter
Red wire goes to
terminal on solenoid
with the positive
battery cable.
Black wire goes to the
ignition switch.
WIRE IDENTIFICATION ON ZT2350
8
