REPLACEMENT PARTS
ITEM NO. PART NO. DESCRIPTION ITEM NO. PART NO. DESCRIPTION
1 SEE DETAIL ENGINE PULLEY CONFIGURATION 25 T30F FINGER BELT GUIDE
2 2450* MOTOR BASE WELDMENT 26 NB213Z 1/2-13 NUT
2451* ADJUSTABLE BELT GUIDE 27 NB566 3/8-16 NUT
3 2418* FRONT GUARD 28 NB107 3/8-16 X 1 1/2 BOLT
NB310 1/4-20 X 1/2 SSC BOLT 29 NB182 3/8-16 NYLOC NUT
5 2448TK BRUSH GUARD 30 T30V V-BELT IDLER PULLEY
6 NB596 5/16-18 X 3/4 FLANGE BOLT 31 NB275 5/16 SAE WASHER
7 NB503 5/16-18 X 1 3/4 BOLT 32 B527 4" IDLER PULLEY
8 2449* DECK WELDMENT 33 NB164 3/8-16 X 3 BOLT
9 2406 RUBBER DEBRIS GUARD 34 BP370S BRAKE SPRING CLIP
10 2424TK RUBBER FLAP STRAP 35 9039 BRAKE PAD
11 2692* REAR COVER ASSEMBLY 36 BT297 BRAKE SPRING
2691* REAR COVER WELDMENT 37 2454TK BLADE IDLER WELDMENT
2417* REAR COVER LATCH 38 NB131 1/2-13 X 3 BOLT
2069 EXTENSION SPRING 39 2460TK TRANSAXLE IDLER WELDMENT
NB501 5/16-18 X 1 BOLT 40 B27 FLAT SIDE IDLER PULLEY
NB170 5/16-18 NUT 41 2462 SEE …BRAKE ASSY DETAIL
B99S SPACER 43 9092 SAFETY SWITCH
2077 YELLOW PLASTIC GRIP 44 NB621 E-CLIPS
12 SEE DETAIL BLADE CONFIGURATION 45 NB524 1/4-20 FLANGE NUT
BA50 BA 50 BELT NB154Z 1/4-20 X 3/4 BOLT
13 SEE DETAIL BLADE IDLER…CONFIG. 46 2434 3/16 X 1 1/2 KEYSTOCK
14 2410 TRANSAXLE PULLEY 47 T2SM SPRING
NB192 SET SCREW 48 NB517 5/16-18 X 1 3/4 CARRIAGE BOLT
2414 TRANSAXLE BELT 49 BB105S ENGINE PULLEY SPACER
15 2447TK SKID RUNNER 50 2437 1/4 X 1 1/2 KEYSTOCK
51 BB105 LOWER ENGINE PULLEY
17 2401L / 2401R POWER TRAX TIRE/WHEEL (SHOWN) 52 699 BELLEVILLE WASHER
2415 SNOW HOG TIRE/WHEEL 53 NB166 3/8-24 X 1 1/4 BOLT
18 2412 PEERLESS TRANSAXLE 54 2411 UPPER ENGINE PULLEY
19 2422TK SAFETY SWITCH MOUNT 55 2413 BELT GUIDE
NB250 1/4-20 X 3/4 BOLT 56 NB175 3/4-16 JAM NUT
20 2456 GEARSHIFT LEVER 57 6114 BLADE DRIVE PULLEY
2427 GEARSHIFT GRIP 58 NB179 THIN WASHER
2423* GEARSHIFT MOUNT 59 6104RS PULLEY SPACER
NB596 5/16-18 X 3/4 FLANGE BOLT 60 9078 BLADE SHAFT
NB503 5/16-18 X 1 3/4 BOLT 61 9091TK STRONG BEARING HOUSING
NB620 1/4-28 X 3/4 BOLT 62 B98 SEALED BEARING
21 2402TK HANDLE 63 NB179 THIN WASHER
22 4291TK BLADE ENGAGE BAIL 64 NB216 3/8-24 CENTER LOCK NUT
23 4294TK GROUND CONTROL BAIL 65 9008 BLADE MOUNT PLATE
2432 TRANSAXLE CABLE 66 90916 24" TOUGH BLADE
24 4254 BLADE LATCH & CABLE ASSY 67 NB166 3/8-24 X 1 1/4 BOLT
NB278 1/4-20 X 1 3/4 BOLT 68 NB607 BELLEVILLE WASHER SERRATED
NB180 1/4-20 NYLOC NUT 69 NB238 3/8-24 X 1 BOLT
* = Paint Code
C = Red
TK = Black
