ENGINE DETAIL
LS826, LS934, LS10534D MODELS
ENGINE DETAIL
LS622 MODEL
ITEM # DESCRIPTION PART #
82 BLACK PLASTIC KNOB 686K
83 THROTTLE & CABLE(NOT SHOWN) 686N
84 ON - OFF KEY SWITCH KSM
85 GOLDEN LOCK WASHER 9088
86 GOLDEN KEY SWITCH NUT 9087
87 EXISTING ENGINE HARDWARE N/A
88 KEY SWITCH PLATE 7415
89 ENGINE N/A
90 5/16-18 X 1 1/4 GR5 BOLT NB504
91 5/16-18 2-WAY LOCK NUT NB558
92 UPPER SPACER BB105SL
93 ENGINE PULLEY BB105
94 LOWER SPACER BB105S
95 BELLEVILLE WASHER 699
96 7/16-20 X 1 GR5 BOLT W/ NYLOCK NB452N
106 KEYSTOCK 9031
NOTSHOWN WIRING HARNESS 9416
NOTSHOWN THROTTLE PLATE/ SCREWS 686P/NB137
ITEM # DESCRIPTION PART #
97 ENGINE N/A
98 5/16-18 X 2 1/2 GR5 BOLT NB138
99 5/16-18 2-WAY LOCK NUT NB558
100 5/16-18 X 1 1/4 GR5 BOLT NB504
101 KEYSTOCK 9030
102 SET SCREW W/ NYLOCK NB312
103 ENGINE PULLEY - LS622 7323
104 BELLEVILLE WASHER 699
105 3/8-24 X 1 BOLT W/ NYLOCK NB238N
89
88
83
82
90
86
85
87
84
91
94
93
92
95
96
100
98 97
99
99
101
105
102
104
103
106
