A.Control Panel
B.120 V, 20 Ampere Duplex Receptacle
20 amps of current may be drawn from each half of the
receptacle. However, total power drawn must be kept within
nameplate ratings. These receptacles may be used along with
the twistlock receptacle provided the generator is not
overloaded.
C.120/240 V, 30 Ampere Twistlock Receptacle
A maximum of 30 amps may be drawn from the 120/240
volt receptacle, provided it is the only receptacle used.
However, current must be limited to the nameplate rating. If
the 120/240 volt receptacle is used along with the 120 volt
receptacle, the total load drawn must not exceed the nameplate
ratings.
D.Circuit Breakers
The receptacles are protected by an AC circuit breaker. If
the generator is overloaded or an external short circuit occurs,
the circuit breaker will trip. If this occurs, disconnect all
electrical loads and try to determine the cause of the problem
before attempting to use the generator again. If overloading
causes the circuit breaker to trip, reduce the load. NOTE:
Continuous tripping of the circuit breaker may cause
damage to generator or equipment. The circuit breaker may
be reset by pushing the button of the breaker.
E.Panel Light
The panel light comes on automatically when the engine
is started. The light goes off automatically when the engine is
shut off.
F.Engine On/Off Switch
G.Engine Start Button
H.Engine Choke Lever
I.Fuel Shut-Off
J.Honda OHV Engine with:
Cast-Iron Cylinder Sleeve
Low Oil Sensor
K.7 Gallon Plastic Fuel Tank
L.Fuel Gauge
M.Generator Head with Automatic Volatage Regulator
(AVR)
N.Storage Bin/Battery Tray
O.Battery Tray Cover
P.Oil Drain
Q.Pneumatic Tires
R.Retractable Handles
S.Handle Release Buttons
To extend the handles, press the handle release buttons on
the wheel end of the unit. Pull the handles out until the handle
release buttons lock in place on the engine end of the unit.
To retract the handles, press the handle release buttons on
the engine end of the unit. Push the handles in until the
handle release buttons lock in place on the wheel end of the
unit.
9
www.powermate.com
Customer Hotline 1-800-445-1805
MAJOR GENERATOR FEATURES
