Generator Exploded View Rev - J
46
Fig # Part # Description Qty
1 777149 Fuel Cap, With Gauge 1
2 38760 Fuel Tank Assembly 1
3 171410 Fuel Clamp 2
4 30754 Leather Washer 4
5 779429 Decal, Control Panel Side 1
6 779464 Decal, Gas Valve Side 1
7 35298 Cradle Weldment 1
8 35844 Nameplate 1
9 31007 Spark Arrester 1
10 778553 Generator Head 1
11 34857 Generator Bracket 1
12 31210 Lead Wire 1
13 34172 Isolation Mounts 4
14 32844 Lower Bracket 4
15 32848 Upper Bracket 4
16 778500 Generator Base 1
17 82018 5/16-18 X 2” Flange Bolt 4
18 35490 Fuel System Components 1
19 33277 10-32 Clip Nut 4
20 32797 10-32 X .75” Socket Head Cap Screw 4
21 35310 Electrical Diagram 1
22 35304 Receptacle Box Weldment 1
23 306579 Grommet 1
24 35296 Engine Mount Plate 1
25 32840 Engine, 20 HP Honda 1
26 777345 Gasoline Fuel Line 18”
27 779396 Battery Decal 1
28 777352 Battery Box 1
29 32839 Battery Cable, Positive 1
30 777108 Battery Cable, Negative 1
