Operation (cont’d)
30
A
djustmen
t
Screw
Lock Nut
3. Starting the Engine
After you have completed the pre-start checklist procedures, you are ready to start the engine.
The following directions detail how to start the engine with either LP/NG or Gasoline as the fuel
source:
Using LP/NG To start engine using LP or Natural Gas:
WARNING:
DO NOT start engine if you smell gas. Exit area immediately
and call gas supplier or fire department. If possible, shut off
gas supply.
1) Disconnect all loads to the generator.
2) Flip fuel selector switch to the LP/NG position.
3) Start the engine:
a) Turn the engine key switch to the START position and hold it there
until the engine starts.
b) When the engine starts, release the key, allowing it to return to the
ON position.
4) It may be necessary to momentarily depress the primer button while
starting the engine, especially for cold starts.
NOTE: If you have trouble starting the engine with LP/NG, you may
need to adjust the load block:
a. Loosen the lock nut, then turn the adjustment screw clockwise
until resistance is felt. At this point the load block is
completely shut-off.
b. While LP or NG is being supplied to the generator, turn the
ignition key to the start position and slowly turn the adjustment
screw counterclockwise until the engine starts. (Depress the
primer button when cold starting the engine.)
c. Once the engine is running, turn the adjustment screw very
slowly to smooth out engine performance.
d. Once the proper setting is achieved turn the brass lock nut to
secure the adjustment screw.
5) Under long, continuous-run operating conditions, be prepared to:
a) Check engine oil level every 24 operating hours,
b) Change oil after the first 20 operating hours, and at least every 100
operating hours thereafter, as directed in the engine owner’s manual.
