Generator Exploded View 165912 – Rev I.3
38
Diag #
Part #
Description
Qty
1
305491
Honda 5 hp Engine
1
2
780422
Engine Adapter Plate
1
4
780423
Fan & bolts
1
5
31193
Drive End Bracket
1
7
780424
Enclosing Band
1
9
306426
120V, 20A, NEMA 5-20R Receptacle
2
10
30643
20A Circuit Breaker
1
11
31177
End Cover
1
14
30815
Hole Plug
1
15
38271
End Cover Plug
1
17
39260
Burning Warning
1
19
306459
Ground Wire
1
20
30963
Engine Bracket
1
21
305587
Isolation Mount
4
22
30964
Front Base Bracket
1
23
780425
Stator
1
24
31218
Nameplate
1
25
780426
Rotor
1
26
307481
Varistor
2
27
780427
Diode
2
28
780428
Securing Stud & nut
1
29
780429
Bearing
1
31
31195
Non Drive End Bracket
1
32
307477
Capacitor
1
33
780431
Bracket Securing Stud
4
34
31178
Cradle Weldment
1
35
779428
Decal
1
36
30965
Generator Bracket
1
37
30966
Back Base Bracket
1
38
780393
Generator
1
