GENERATOR FEATURES
Reference 1 - Circuit Breakers. This belt driven
single phase generator has 2, 20 amp (A) push to
reset circuit breakers to protect against electrical
overloads.
Receptacles
Reference 2 - 120V Receptacle. The generator
has an end cover with one duplex (two receptacles in
a common housing) receptacle and one locking device
receptacle. The duplex is a 120 volt (V) 20 amp (A)
straight blade receptacle, National Electrical
Manufacturer’s Association (NEMA) number 5-20R.
This receptacle accepts NEMA plug numbers 5-15P
and 5-20P. Each receptacle on the duplex is capable
of drawing 20A.
Reference 3 - 240V Receptacle. The locking
device is a 240V 20A NEMA L6-20R receptacle. This
receptacle accepts a NEMA plug number L6-20P.
ALWAYS use grounded male plugs. The neutral
line of the generator is mechanically grounded to the
fram e. Matching NEMA male pl ugs must al ways be
used.
Reference 4 - Ground Screw . Ground the
generator via the ground screw, to a copper pipe or
rod that is driven into moist soil.
Reference 5 - 7/8” diameter Shaft. The shaft is
1.50” long and has a 3/16” keyway.
Reference 6 - Mounting feet. Use these three
locations to bolt the generator head in place.
Reference 7 - Fan Vents. Never block the vent
sl ots o r i nse rt ob jects th roug h t he sl o ts.
INTRODUCTION
Before attempting to mount your generator,
thoroughly study the instructions and cautions in this
manual to assure you are fully acquainted with the
operation of all components of this generator. Proper
preparation, operation and maintenance will result in
operator safety, best performance and long life of the
generator.
North Star is constantly improving its products.
The specifications outlined herein are subject to
change without prior notice or obligation. The
purchaser and/or user assumes liability of any
modification and/or alterations on this equipm ent from
original design and manufacture.
Before using, the user shall determine the
suitability of this product for its intended use and
assumes liability therein.
ANSI SAFETY DEFINITIONS
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury. This signal word is to be limited to the
most extreme situations.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in a
death or seri ous i nj ury.
CAUT ION indicates a potentially hazardous
situation, which if not avoided, may result in minor or
moderate injury. It may also be used to alert against
unsafe practices.
RULES FOR SAFE OPERATIONS
Safety precautions are essential when operating
this generator. Respectful and cautious operation will
considerably lessen the possibilities of a personal
injury. This manual will warn of specific personal injury
potential, and these will be designated by the symbol:
WARNING This generator is equipped
with a grounding screw, located on the generator
frame for your protection. Always complete the
grounding path from the generator to a copper
pipe/rod that is driven into moist earth, to prevent
electrical shock.
ALWAYS use electrical cords that are in good
condition. Worn, bare, frayed or otherwise damaged
cords can cause electric shock.
NEVER operate the generator, or handle any
electrical equipm ent while standing in water, while
barefoot, while hands are wet or while in the rain or
snow. Electric shock may result.
ALWAYS use a ground fault circuit interrupter
(GFCI) in damp or highly electrical conductive areas
and on construction job-sites to prevent electric shock.
ALWAYS remove the spark plug or spark plug
wire before working on the engine or generator, this
prevents accidental starting.
ALWAYS provide adequate ventilation. Do not
operate generator in any enclosed or narrow space.
Engines consume oxygen and give off deadly carbon
monoxide, a poisonous gas. Improper ventilation will
cause damage to generator and possible injury to
people.
