Reference 21 - 120/240V 20A Receptacle. One
twistlock 120/240V receptacle capable of drawing 20
amps, (NEMA) number L14-20R. This receptacle accepts
only NEMA 14-20P plugs, one of which is shipped with the
generator. Use this receptacle if installing a transfer switch.
Compatible with Gentran transfer switch, item #16411.
Reference 22 - Grounding Post. Ground the
generator via the grounding post, to a copper pipe or rod
that is driven down until it reaches moist soil.
References 23-25 - 120V Receptacles. The
generator has a control panel with:
• Reference 23 - two duplex (two receptacles in a
common housing) 120V GFCI straight-blade
receptacles capable of drawing 20 amp, National
Electrical Manufacturer’s Association (NEMA) part
number 5-20R. These receptacles accept NEMA
numbers 5-15P or 5-20P plugs.
• Reference 24 - one straight-blade 120V receptacle
capable of drawing 50 amp, NEMA 5-50R. This
accepts only NEMA 5-50P plugs, one of which is
shipped with the generator.
• Reference 25 - one twistlock 120V receptacle
capable of drawing 30 amps, (NEMA) number L5-30R.
This receptacle accepts only NEMA number 5-30P
plugs, one of which is shipped with the generator.
ALWAYS use grounded male plugs. The neutral line
of the generator is mechanically grounded to the
frame. Matchi ng NEMA male pl ugs must always be
used.
WARNING Contact a licensed electrician to
wire electrical plugs and/or cordsets. Improper wiring
could result in a fire or electrical shock. Never use
defective or broken plugs or receptacles.
References 26-28 - Circuit Breakers. This portable
single phase generator has
• Reference 26 - (2) 20 amp (A) push-to-reset circuit
breakers.
• Reference 27 - (1) 30A push-to-reset circuit breaker
• Reference 28 - (1) 20A magnetic 2 pole main circuit
breaker to protect against electrical overloads.
Reference 29 - Hour Meter. Allows for a better
maintenance schedule of the generator.
Low Oil Shutdown. The Honda engine is protected
against damage resulting from low oil level. As the oil falls
below the safe level, the engine automatically shuts off
(the engine stop switch remains in the on position). The
engine will not start until the oil is refilled to above the safe
level.
INTRODUCTION
Before starting your generator, thoroughly study the
instructions and cautions in this manual to assure you are
fully acquainted with the operation of all components of
this generator. Proper preparation, operation and
maintenance will result in operator safety, best
performance and long life of the generator. For detailed
engine operation and maintenance always refer to the
Honda engine owner’s manual furnished with the
generator (Honda refers to the 9 HP engine as a GX270).
North Star is constantly improving its products. The
specifications outlined herein are subject to change
without prior notice or obligation. The purchaser and/or
user assumes liability of any modification and/or
alterations on this equipment from original design and
manufacture.
Before using, the user shall determine the suitability of
this product for its intended use and assumes liability
therei n.
ANSI SAFETY DEFINITIONS
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury. This signal word is to be limited to the most
extreme situations.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in a death or
serious injury.
CAUTION indicates a potentially hazardous
situation, which if not avoided, may result in minor or
moderate injury. It may also be used to alert against
unsafe practices.
RULES FOR SAFE OPERATIONS
Safety precautions are essential when operating this
generator. Respectful and cautious operation will
considerably lessen the possibilities of a personal injury.
This manual will warn of specific personal injury potential,
and these will be designated by the symbol:
WARNING This generator is equipped with a
grounding post, located on the control panel for your
protection. Always complete the grounding path from the
generator to a copper pipe/rod that is driven into moist
earth, to prevent electrical shock.
ALWAYS use electrical cords that are in good
condition. Worn, bare, frayed or otherwise damaged cords
can cause electric shock.
NEVER operate the generator, or handle any electrical
equipment while standing in water, while barefoot, while
hands are wet or while in the rain or snow. Electric shock
may result.
ALWAYS use a ground fault circuit interrupter (GFCI)
in damp or highly electrical conductive areas and on
construction job-sites to prevent electric shock.
