Maximum Output 27500 Watts (W)
Continuous Output 24000 W
Voltage 120 / 240 Volt (V)
Phase Single phase (4-wire)
Frequency 59.0-63.0 Hertz (Hz)
Power Factor 1.0
Minimum PTO HP 48 HP at 540 RPM
Input Shaft 1 3/8” Diameter, 6 spline
120V Receptacle (2) 20 Amp (A) duplex (NEMA 5-20R)
30A Twistlock (NEMA L5-30R)
120/240V Receptacle 60A Straight blade (NEMA 14-60R)
100A Pin and sleeve (4100R12W)
Circuit Breaker (2) 20A thermal, push to reset style
30A thermal, push to reset style
60A thermal magnetic
100A thermal magnetic
Gear Box
Gear Ratio 1:7
Gear Oil SAE 80W-90
Oil Capacity .53 Qt. (.5 L)
Dimensions
Length 36.95” (93.9 cm)
Width 16.85” (42.8 cm)
Height 20.79” (52.8 cm)
Gross Weight 425 lb. (193.2 kg)
ANSI SAFETY DEFINITIONS
DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury. This signal word is to be limited to the most
extreme situations.
WARNING indicates a potentially hazardous situation which, if not avoided, could
result in a death or serious injury.
CAUTION indicates a potentially hazardous situation, which if not avoided, may
result in minor or moderate injury. It may also be used to alert against unsafe
practices.
MACHINE COMPONENT IDENTIFICATION
