GAC9.7HZ 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #2 (03/31/10) — PAGE 67
NO. PART NO. PART NAME QTY. REMARKS
1♦ 30500ZJ1841 COIL ASSY., IGNITION ......................................1................USE UP TO S/N 2018397
1♦ 30500ZJ1842 COIL ASSY., IGNITION ......................................1................S/N's 2018398~2047154
1♦ 30500ZJ1843 COIL ASSY., IGNITION ......................................1................S/N's 2047155~2049300
1♦ 30500ZJ1844 COIL ASSY., IGNITION ......................................1................USE FROM S/N 2049301
1◊ 30500ZJ1844 COIL ASSY., IGNITION ......................................1................USE UP TO S/N 1020628
1◊ 30500ZJ1845 COIL ASSY., IGNITION ......................................1................USE FROM S/N 1020629
2 30518ZJ1000 GROMMET, HIGH TENSION WIRE 2
4 30700ZJ1841 CAP ASSY., NOISE SUPPRESSOR 2
5 31510ZE1811 COIL ASSY., CHARGE (12V/3A) 1
7♦ 31740ZJ1851 DOIDE ASSY., ENGINE STOP 1 INCLUDES ITEM W/#
7◊ 31740ZJ1851 DOIDE ASSY., ENGINE STOP ..........................1................USE UP TO S/N 1065525
7◊ 31740ZJ1852 DOIDE ASSY., ENGINE STOP ..........................1................USE FROM S/N 1065526
8# 63312ZA7000 GROMMET, TOOL
9 90031ZE1000 BOLT, FLANGE (6X32) 2
11 90031ZE1000 BOLT, FLANGE (6X32) 2
15 957010600800 BOLT, FLANGE (6X8) 1
16 32763PA0000 CLAMP, CORD 1
17 31630ZJ0881 COIL ASSY., CHARGE (12V/3A) 1
19♦ 30500ZJ1841 COIL ASSY., IGNITION ......................................1................USE UP TO S/N 2018565
19♦ 30500ZJ1842 COIL ASSY., IGNITION ......................................1................S/N's 2018566~2047154
19♦ 30500ZJ1843 COIL ASSY., IGNITION ......................................1................S/N's 2047155~2049300
19♦ 30500ZJ1844 COIL ASSY., IGNITION ......................................1................USE FROM S/N 2049301
19◊ 30500ZJ1844 COIL ASSY., IGNITION ......................................1................USE UP TO S/N 1020628
19◊ 30500ZJ1845 COIL ASSY., IGNITION ......................................1................USE FROM S/N 1020629
HONDA GX610K1VD/U1VD ENGINE — IGNITION COIL ASSY.
♦GX610K1VD: Model GAC9.7HZ AUG. 2007 AND BELOW
◊ GX610U1VD: Model GAC9.7HZ JAN. 2008 AND ABOVE
